Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall workstation dimensions | 2000 x 1800 x 1200 mm | |
|---|---|---|
| desktop standard working height | 750 mm | |
| main desktop leg length | 1600 mm | |
| desktop surface depth | 600 mm | |
| desktop panel thickness | 25 mm | |
| edge band thickness | 2 mm | |
| under-desk seated knee clearance height | 650 mm | |
| knee well horizontal clearance width | 800 mm | |
| 3-drawer pedestal dimensions | 400 x 600 x 700 mm | |
| corner double-door cabinet dimensions | 800 x 600 x 700 mm | |
| adjacent workstation surface length | 1200 mm | |
| total partition screen height | 1200 mm | |
| lower fabric modesty panel height | 350 mm | |
| upper slatted translucent screen height | 450 mm | |
| cable pass-through slot width | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static load capacity | 91 kg | |
|---|---|---|
| single drawer slide static load | 25 kg | |
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| laminate surface abrasion resistance | 2000 cycles | |
| recommended maximum user weight | 113 kg | |
| modular connected workstation capacity per run | 8 seats | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| work surface | 25mm thick E1 grade particleboard with light oak thermofused laminate | |
|---|---|---|
| cabinet bodies and fronts | 18mm E1 grade particleboard with white/light oak melamine finish | |
| partition support frames | 1.2mm thick powder-coated square steel tubing | |
| lower partition panels | 18mm thick MDF core wrapped in green woven polyester fabric | |
| upper partition slats | 3mm thick frosted translucent acrylic or hardboard slats | |
| drawer and cabinet hardware | Zinc-plated steel handles, ball-bearing slides, keyed cam locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| lockable storage pedestals | Keyed 3-drawer pedestals with two supply drawers and one hanging file drawer | |
|---|---|---|
| cable management system | Slotted pass-through openings in partition frames for wire routing between desk and power/data sources | |
| mobile CPU stand | Rolling two-wheeled CPU holder under corner knee well with free-sliding track | |
| modular partition connection | 90-degree corner steel connectors to link partitions for multi-seat layout expansion |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| open plan office staff workstations | Modular design supports multi-seat cluster layouts with controlled privacy | |
|---|---|---|
| small office corner workspaces | L-shaped footprint fits room corners to maximize usable floor space |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2015 | Office worktables safety and strength requirements, applicable to desk stability and load testing | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic reference for desk dimensions and clearance design |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to surface load, hardware durability and stability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate desk and cabinet components | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks, applicable to work surface load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate desk and cabinet components; 2. GB/T 3327-2017: Performance requirements for office desks, applicable to work surface load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
