Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (2-person unit) | 2840 x 1440 x 1150 mm | |
|---|---|---|
| Working surface height | 750 mm | |
| Partition total height above floor | 1150 mm | |
| Knee recess height under desk | 650 mm | |
| Desktop thickness | 25 mm | |
| Privacy partition panel thickness | 60 mm | |
| Lower storage cabinet internal usable height | 450 mm | |
| Cable grommet diameter | 80 mm | |
| Aluminum partition frame wall thickness | 1.2 mm | |
| Storage pedestal width (per station) | 450 mm | |
| Work surface depth per seating position | 700 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total unit net weight | 165 kg | |
|---|---|---|
| Desktop static load capacity | 120 kg | |
| Storage cabinet shelf static load | 40 kg | |
| Privacy panel sound transmission class (STC) | 30 dB | |
| Recommended user capacity | 2 people | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Manufacturer warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desk work surface | E1 grade melamine-faced particleboard (MFC) with 2mm PVC edge banding | |
|---|---|---|
| Privacy partition facing | Dark woven fabric over high-density fiber core | |
| Partition support frame | Anodized aluminum extrusions with gray/blue powder coated finish | |
| Storage cabinet carcass | White melamine-faced particleboard with matching PVC edge banding | |
| Under-desk modesty panel | Black fabric-covered rigid panel matching partition finish | |
| Drawer and door hardware | Silver aluminum pull handles, keyed cam lock, steel drawer slides | |
| Partition core fill | High-density polyester acoustic fiber fill | |
| Leveling feet | Nylon-tipped steel adjustable glides at all base contact points | |
| Cable grommet | Black ABS plastic round cable pass-through | |
| Structural cabinet base plinth | White laminated particleboard plinth with protective PVC edge trim | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Curved corner knee recess | Concave curved worktop edge providing unobstructed legroom for seated users | |
|---|---|---|
| Integrated lockable storage per seat | 1 top lockable drawer plus 1 lower hinged door cabinet per user position | |
| Desktop cable management | Round corner cable grommet routes power/data cables from desk top to under-desk space | |
| Modular privacy partition system | Interlocking corner and side panels divide adjacent workstations for visual privacy | |
| Adjustable leveling feet | Threaded glides at all base points adjust to compensate for uneven office floors | |
| Under-desk modesty panel | Black fabric panel blocks view of seated user's legs from adjacent walkways | |
| Under-desk cable routing path | Open under-desk space allows installation of optional cable raceways for cord organization | |
| Reconfigurable panel connections | Aluminum frame connectors allow addition of extra panels for larger workstation layouts | |
| Lockable drawer internal usable height | 150 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Provides divided personal workspaces for teams in open office layouts | |
|---|---|---|
| Corporate administrative departments | Suitable for HR, finance, and operations teams needing storage and privacy | |
| Small business shared office spaces | Compact 2-person layout fits small floorplans while separating work zones | |
| Call center and customer service floors | Low partitions allow team visibility while reducing cross-talk distraction | |
| Government agency office areas | Durable construction and lockable storage meet secure document handling needs | |
| Co-working space dedicated desk zones | Fixed assigned stations with personal storage for long-term co-working members |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and performance requirements, applicable to work surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture seating dimensions reference for compatible knee clearance design | |
| EN 1023-2:2000 | Office storage furniture safety requirements for drawers and cabinet doors | |
| EN 13501-1:2018 | Fire classification for construction and furniture panel materials |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer and cabinet testing | |
| ANSI/BIFMA X7.1-2022 | Formaldehyde emission standard for low-emitting office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and cabinet components | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for engineered wood products, applicable to board components | |
| GB/T 35607-2017 | Performance requirements for office furniture work desks, applicable to work surface and structure | |
| GB 20286-2006 | Flame retardant requirements for public place furniture components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and cabinet components; 2. GB 18580-2017: Formaldehyde emission limits for engineered wood products, applicable to board components; 3. GB/T 35607-2017: Performance requirements for office furniture work desks, applicable to work surface and structure; 4. GB 20286-2006: Flame retardant requirements for public place furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
