2-Person Modular Office Cubicle Workstation with Mobile Pedestals (model CW-OAK-WH-2P-24060) is listed under L-Shaped Office Desk, with overall dimensions of 2400 × 1200 × 1100 mm and main material of Particle‑board (PB). Load capacity: 300 kg. Certifications: low-partition,modular,two-seat,cluster,oak-white,finish,mobile,under-desk,storage,integrated,cable,management. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 2400 x 1200 x 1100 mm | |
|---|---|---|
| Individual work surface per seat | 1200 x 600 x 750 mm | |
| Work surface thickness | 25 mm | |
| Steel support frame section | 60 x 30 x 1.2 mm | |
| Partition panel thickness | 32 mm | |
| Under-desk knee clearance height | 600 mm | |
| Under-desk knee clearance depth | 550 mm | |
| 3-drawer mobile pedestal dimensions | 400 x 550 x 600 mm | |
| Desktop privacy screen height above worktop | 350 mm | |
| Frame leg adjustable foot diameter | 30 mm | |
| Cable access cutout diameter | 80 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total work surface static load capacity | 300 kg | |
|---|---|---|
| Workstation unit net weight | 112 kg | |
| Mobile pedestal caster load rating per caster | 40 kg | |
| Surface scratch resistance cycles | 100000 cycles | |
| Frame rust resistance salt spray test | 48 hours | |
| Workstation structural service life | 10 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1 grade particle board with oak grain melamine laminate | |
|---|---|---|
| Support frame | 1.2mm thick powder-coated white steel rectangular tubing | |
| Privacy panels | Melamine-faced particle board with white lower panel and oak upper trim | |
| Mobile pedestal | Melamine-coated chipboard with oak finish, integrated lock, metal drawer runners | |
| Cable management components | Aluminum under-desk cable tray with desktop grommets | |
| Leveling feet | Reinforced nylon adjustable feet with anti-slip rubber base |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating capacity | 2 individual seated office users | |
|---|---|---|
| Cable management | Under-desk cable tray and desktop grommets route power/data cables | |
| Mobile storage pedestals | 3 lockable drawers per position on 4 swivel casters | |
| Modular reconfiguration | Bolted partition connectors allow extension to 4/6/8 person clusters |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan corporate offices | Creates defined individual workspaces with low partitions for team collaboration | |
|---|---|---|
| Coworking spaces | Modular layout supports flexible seat allocation for flexible working models |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture workstation dimensions for seated use, applicable to clearance requirements | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to mobile pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and durability standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for mobile pedestal durability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate worktops and panels | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel support frame | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade board components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate worktops and panels; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel support frame; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade board components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
