Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (W×D×H) | 2800 × 1425 × 1200 mm | |
|---|---|---|
| Single L-shaped work surface main segment width | 1400 mm | |
| Single L-shaped work surface return segment depth | 600 mm | |
| Work surface thickness | 25 mm | |
| Perforated upper privacy panel height | 450 mm | |
| Solid lower modesty panel height | 400 mm | |
| Divider partition thickness | 32 mm | |
| Seated knee clearance width per position | 600 mm | |
| Seated knee clearance height under desk | 650 mm | |
| Pedestal drawer front height | 150 mm | |
| Lower pedestal storage compartment height | 500 mm | |
| Support leg diameter | 30 mm | |
| Work surface edge banding thickness | 2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total assembled product weight | 100 kg | |
|---|---|---|
| Uniform static load per work surface | 136 kg | |
| Lockable drawer static load capacity | 25 kg | |
| Recommended number of users | 2 | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Leveler adjustment range per leg | 15 mm | |
| Manufacturer warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | E1 grade particle board with thermally fused laminate | |
|---|---|---|
| Work surface edge treatment | 2 mm PVC edge banding | |
| Upper partition panels | Perforated powder-coated steel mesh with aluminum framing | |
| Lower modesty panels | Melamine-faced engineered board | |
| Support legs | Powder-coated dark steel tapered legs with integrated leveling glides | |
| Drawer and cabinet fronts | Two-tone laminate engineered board (light cream base, taupe drawer accent) | |
| Hardware components | Zinc-plated steel cam locks, drawer slides and connecting fasteners | |
| Pedestal structure | 18 mm thick engineered board carcass with laminated interior finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Separated by T-shaped central divider to eliminate cross-visual distraction between users | |
|---|---|---|
| Per-position lockable storage | One lockable top drawer and one enclosed lower cabinet per user for securing personal items | |
| Integrated seated knee clearance | Open central leg well per position allows unobstructed seated posture and chair movement | |
| Floor leveling adjustment | Adjustable glides on all support legs compensate for uneven office flooring | |
| Cable management access | Desk surface grommet provision for routing power and data cables to desk equipment | |
| Modular connection capability | Partition frame hardware allows connection to additional cubicle modules for expanded office layouts | |
| Privacy screening | Dual-height divider with perforated upper panel provides airflow and visual privacy while maintaining open office acoustics | |
| Freestanding installation | No wall mounting required, positioned directly on finished office floors using integrated leg levelers | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff zones | Provides individual divided workspaces for administrative, operations or back-office staff | |
|---|---|---|
| Small business startup offices | Space-efficient corner layout fits two work positions without custom cubicle construction | |
| Call center and shared work areas | Perforated dividers reduce distraction while maintaining open air circulation for high-density seating | |
| Temporary project team spaces | Modular design allows reconfiguration as team sizes change over project durations | |
| Satellite branch office setups | Flat-pack design ships efficiently for outfitting remote small office locations | |
| Recommended configuration | Pair with two mid-back ergonomic office chairs, under-desk CPU holders and monitor arms for full work setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial desk surfaces | |
|---|---|---|
| EN 527-2:2019 | Office worktables dimensional, mechanical strength and stability requirements | |
| EN 1335-1:2020 | Office furniture workstation dimensional compatibility with office seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance, load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.6-2022 | Panel systems standard for cubicle divider strength and stability | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and recyclability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and pedestal components | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture, applicable to legs, frames and divider hardware | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood products, required for indoor office use | |
| GB/T 10357.1-2013 | Desk strength and stability test methods for surface load and structural performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and pedestal components; 2. GB/T 3325-2017: Test methods for metal furniture, applicable to legs, frames and divider hardware; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood products, required for indoor office use; 4. GB/T 10357.1-2013: Desk strength and stability test methods for surface load and structural performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
