Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1600 x 1600 x 1200 mm | |
|---|---|---|
| Desktop working height | 730 mm | |
| Desktop surface thickness | 25 mm | |
| Main desktop usable depth | 700 mm | |
| Knee well clearance height | 680 mm | |
| Knee well clear width at entry | 800 mm | |
| Partition panel thickness | 40 mm | |
| Integrated storage pedestal dimensions | 800 x 400 x 725 mm | |
| Top drawer internal height | 120 mm | |
| Lower cabinet internal height | 550 mm | |
| Cable grommet diameter | 80 mm | |
| Aluminum partition frame profile wall thickness | 1.2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 95 kg | |
| Recommended user weight capacity | 120 kg | |
| Finish scratch resistance rating | 2000 cycles | |
| Connector disassembly cycle rating | 50 cycles | |
| Standard warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E0-grade particleboard, formaldehyde emission ≤0.5mg/L | |
|---|---|---|
| Desktop surface finish | Light maple melamine laminate, stain and scratch resistant | |
| Desktop edge banding | 2mm thick PVC edge banding, impact and water resistant | |
| Partition frame | Gray powder-coated aluminum alloy profile, 1.2mm wall thickness | |
| Lower partition panel | Gray tackable fabric panel, sound dampening | |
| Upper partition panel | Clear tempered glass panel, 4mm thickness | |
| Storage cabinet body | White melamine-faced particleboard, matching edge banding | |
| Hardware components | Zinc alloy lock, chrome-plated steel pull handles, adjustable leveling feet | |
| Modesty panel | Gray fabric-covered composite panel, fixed under desk front | |
| Drawer slides | Three-section ball-bearing steel slides, full extension | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | 80mm round grommet at desk corner routes power and data cables to under-desk space | |
|---|---|---|
| Drawer lock function | Central key lock secures top drawer for personal item storage | |
| Storage access | 1 full-extension top drawer and 1 hinged lower cabinet door for enclosed storage | |
| Partition privacy | 400mm high solid lower fabric panel blocks seated sightlines, upper glass maintains light transmission | |
| Modular connection | Pre-drilled frame connectors allow attachment to adjacent cubicle units for cluster layouts | |
| Leveling adjustment | Adjustable foot glides at each base corner compensate for uneven office floors | |
| Fabric panel utility | Tackable lower fabric surface supports pinned notes and documents without damaging panels | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office layouts | Provides individual seated privacy without full-height wall separation for team environments | |
|---|---|---|
| Call center and administrative work areas | Compact L-shaped footprint fits high-density workstation cluster configurations | |
| Startup and SME office spaces | Integrated storage eliminates need for separate cabinets, reduces space requirements | |
| Multi-station cubicle banks | Modular frame design connects to matching units to create 2/4/6-seat workstation clusters | |
| Government and corporate procurement projects | Meets standard office furniture technical specifications for bulk tender requirements | |
| Long-term daily office use | Durable construction and hardware support 8+ hours daily use over 5+ year service life | |
| Wired and hybrid work setups | Integrated cable management supports monitors, PCs and office equipment wiring |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic dimensions reference for desk height and clearance | |
| EN 1022:2019 | Furniture seating and table stability testing standards, applicable to unit stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer and cabinet load rating verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and cabinet components | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks, applicable to work surface and structure testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for E0-grade substrate verification | |
| GB/T 4897-2015 | Particleboard performance standards, applicable to desk and cabinet panel substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and cabinet components; 2. GB/T 3327-2016: Performance requirements for office desks, applicable to work surface and structure testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for E0-grade substrate verification; 4. GB/T 4897-2015: Particleboard performance standards, applicable to desk and cabinet panel substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
