Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 2800 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height from floor | 750 mm | |
| Rear privacy partition height above floor | 1200 mm | |
| Central divider partition height above worktop | 350 mm | |
| Individual work surface per user | 1400 x 600 mm | |
| Desk panel thickness | 25 mm | |
| Privacy partition panel thickness | 40 mm | |
| Under-desk knee clearance height | 650 mm | |
| Knee clearance depth per seat | 500 mm | |
| Integrated storage pedestal dimensions | 400 x 500 x 600 mm | |
| Metal support leg diameter | 30 mm | |
| Worktop edge banding thickness | 2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Work surface static load capacity per seat | 120 kg | |
|---|---|---|
| Partition panel sound absorption coefficient | 0.35 | |
| Work surface scratch resistance rating | 2000 cycles | |
| Workstation net weight | 115 kg | |
| Recommended user capacity | 2 people | |
| Product warranty period | 5 years | |
| Surface stain and water resistance | Yes, wipe-clean melamine finish | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade melamine-faced particleboard, 25mm thick | |
|---|---|---|
| Partition panel core | High-density particleboard core with fabric face, white steel frame | |
| Storage cabinet panels | 18mm thick melamine-faced MDF, two-tone beige/white finish | |
| Edge banding | 2mm thick PVC edging on all exposed worktop edges | |
| Support legs and base frames | 20mm square black powder-coated steel tube | |
| Partition framing | White powder-coated extruded aluminum profile framing | |
| Storage hardware | Zinc alloy keyed drawer locks, chrome-plated steel hinges | |
| Cable management components | ABS plastic cable grommets and under-desk raceway | |
| Modular connecting hardware | Steel cam lock and bolt assembly for KD construction | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Privacy separation | Full rear partition and central divider block cross-user line of sight | |
|---|---|---|
| Storage security | Each pedestal includes 1 key-locked drawer and 1 hinged cabinet door | |
| Cable routing | 1 desk grommet per work position leads to under-desk cable raceway | |
| Modular expandability | Bolt-together aluminum frame allows connection to additional workstation modules | |
| Floor clearance | 50 mm clearance under storage pedestals allows floor cleaning access | |
| Adjustable feet | Threaded adjustable glides on leg bases compensate for uneven floor surfaces | |
| Work surface orientation | Right-angle L-layout supports two users facing perpendicular directions | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Packaging configuration | 3 flat-pack cartons, 5-ply corrugated export grade | |
|---|---|---|
| Largest carton dimensions | 1650 x 850 x 120 mm | |
| Total packaged gross weight | 135 kg | |
| Container loading quantity (40ft HQ) | 120 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Suits staff zones requiring quiet separation between adjacent workers | |
|---|---|---|
| Small business and startup offices | Compact L-layout fits tight floor plans while providing two work positions | |
| Co-working flexible office spaces | Modular design supports reconfiguration as team sizes change | |
| Call center and back-office operations | Partitions reduce visual interruption for focused screen-based work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worktop performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic reference for work surface height dimensions | |
| EN 1023-1:2020 | Office storage furniture strength requirements, applicable to lockable pedestals |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel components | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks and workstations, applicable to structural performance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel components; 2. GB/T 3327-2016: Technical requirements for office desks and workstations, applicable to structural performance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
