PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2800 × 2800 × 1200 mm
Overall cluster footprint	2800 x 2800 x 1200 mm
Worksurface height above floor	750 mm
Single L-worksurface segment dimensions	1400 x 1200 mm
Curved knee clearance width per seat	600 mm
Knee clearance height below worksurface	650 mm
Privacy partition thickness	32 mm
Partition height above worksurface	450 mm
Worksurface panel thickness	25 mm
PVC edge banding thickness	2 mm
Mobile pedestal dimensions per unit	400 x 500 x 600 mm
Cable grommet diameter	60 mm
Side elevated storage shelf dimensions	800 x 400 x 300 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Worksurface static load capacity	91 kg
Drawer slide cycle rating	50000 cycles
Assembly weight per set	180 kg
Recommended user capacity	2 people
Laminate surface abrasion resistance	2000 cycles
Product structural warranty	5 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worksurface core	E1 grade melamine-faced particle board (MFC)
Worksurface edge trim	2mm thick PVC edge banding
Privacy partition frame	Powder-coated square aluminum tubing
Partition face panels	Sage green fabric over medium-density fiberboard core
Partition upper vented section	Perforated light oak-look engineered wood panel
Mobile pedestal body	Light oak-look melamine-faced particle board
Pedestal drawer front accent	Sage green painted/melamine MDF panel
Caster wheels for pedestals	50mm diameter black nylon swivel casters
Desk modesty panel	Light oak-look melamine MDF with grooved textured finish
Cable management components	Rigid PVC cable raceways mounted below worksurface
Rear side storage cabinet frame	Melamine-faced particle board with lockable drawer
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seated work layout	Two mirrored L-shaped positions with curved concave knee cutouts for ergonomic seated access
Mobile pedestal storage	Lockable 3-drawer rolling pedestal per seat, fits fully under worksurface when not in use
Privacy screening	Partial-height dividers block direct line of sight between adjacent workers while allowing overhead communication
Cable management	Rear cable raceway and desktop grommet route power/data cables between floor outlets and desk devices
Elevated side storage	Open shelf above partition per seat for small plants, documents, or personal items
Rear fixed side storage	Lockable single-drawer cabinet per seat at outer desk end for additional office supply storage
Modular connectivity	Corner joint connects two workstation units for stable clustered 90-degree installation
Caster mobility for pedestals	Four swivel casters per pedestal allow 360-degree rolling for easy repositioning and cleaning access
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office staff areas	Provides individual work zones with privacy for regular administrative and task work
Small business team workspaces	Compact 2-person cluster fits small team rooms without overcrowding
Startup office spaces	Modular knock-down design supports quick reconfiguration as team size changes
Shared service center work floors	Durable laminate surfaces withstand daily heavy use for high-traffic work environments
Call center pod configurations	Partial dividers reduce visual distraction while allowing supervisor access from aisles

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office worktables safety and strength requirements for commercial office use
EN 527-2:2016	Office worktables dimensional and safety adjustment requirements for fixed-height desks
EN 1335-2:2009	Reference for office furniture stability relevant to clustered workstation installation
EN 71-3:2019+A1:2021	Migration of certain elements for surface finish safety, applicable to edge and panel coatings

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products safety and performance standard for commercial office applications
ANSI/BIFMA X5.9-2019	Storage units performance standard applicable to included pedestal and cabinet storage

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to worksurface and cabinet components
GB/T 3327-2016	Stability, strength and durability requirements for office desks and workstations
GB 18580-2017	Formaldehyde emission limits for wood-based panels used in interior furniture
GB/T 10357.1-2013	Table mechanical performance test methods for load and durability validation

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worksurface and cabinet components;
2. GB/T 3327-2016: Stability, strength and durability requirements for office desks and workstations;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels used in interior furniture;
4. GB/T 10357.1-2013: Table mechanical performance test methods for load and durability validation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-L2C-2800

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-L2C-2800

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-L2C-2800Open Export Tool

Quick Actions

Post an RFQ

Product Description

The WS-L2C-2800 is a 2-person 90-degree L-shaped office cubicle workstation with coordinated mobile pedestals, designed as a compact, functional shared work cluster. Its visual design features a coordinated two-tone wood-sage finish: light oak-look engineered wood forms worksurfaces, modesty panels, vented partition upper sections, and pedestal bodies, paired with soft sage green fabric privacy panel faces and matching sage pedestal drawer accents, creating a calm, professional aesthetic. The 2800 x 2800 x 1200 mm cluster arranges two mirrored L-shaped work positions around a central corner joint, with partial-height dividers separating adjacent seats while preserving open sightlines above partition tops for easy team communication. Each 1400 x 1200 mm L-worksurface segment sits 750 mm above the floor, with curved concave knee cutouts delivering 600 mm of clearance width and 650 mm of vertical knee space per seat for ergonomic access. Construction uses durable, commercial-grade materials: 25 mm thick E1 grade melamine-faced particle board for worksurfaces, finished with 2 mm PVC edge banding to resist impact damage. 32 mm thick privacy partitions are framed with powder-coated square aluminum tubing, with fabric-covered medium-density fiberboard lower panels and perforated light oak-look upper sections, supported by a powder-coated metal frame for long-term structural stability. Each mobile pedestal features 50 mm black nylon swivel casters, with a lockable 3-drawer design that tucks fully under the worksurface when not in use. Additional functional elements include a rear cable raceway and desktop grommets to organize power and data cords, an open elevated shelf above each partition for small personal items or documents, a lockable single-drawer cabinet at the outer end of each desk for extra supply storage, and partial-height privacy screens that reduce visual distraction without blocking overhead interaction. The worksurface supports a 91 kg static load and 150 kg uniformly distributed load, with laminate surfaces rated for 2000 abrasion cycles and drawer slides tested to 50000 open-close cycles for consistent heavy use. This workstation is well suited for open-plan office staff zones, small business team rooms, startup offices that need flexible reconfiguration, high-traffic shared service center floors, and call center pod layouts that balance individual focus with easy supervisor access. For procurement, note each set ships with a total packaged weight of 180 kg across cartons occupying 1 cubic meter of space, requires 40 minutes of assembly time per unit, and comes with a 5-year structural warranty. The unbranded modular design supports clustered installation as team needs evolve, and the 180 kg per set assembly weight should be accounted for during delivery and installation planning.

2-Person 90-Degree L-Shaped Office Cubicle Workstation with Mobile Pedestals Specifications
