Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 2800 x 2800 x 1200 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Per-seat individual worktop size | 1400 x 700 mm | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Privacy divider total height above floor | 1200 mm | |
| Seated knee clearance height | 680 mm | |
| Seated knee clearance depth | 500 mm | |
| Integrated per-seat pedestal size | 400 x 500 x 650 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Support steel beam section | 40 x 40 mm | |
| Support steel wall thickness | 1.5 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight (per full set) | 125 kg | |
|---|---|---|
| Worktop static uniform load capacity | 100 kg | |
| Single drawer slide load rating | 25 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Divider panel static stability load | 30 kg | |
| Seating capacity | 4 users | |
| Melamine surface abrasion resistance | 2000 revolutions | |
| Surface heat resistance | 120 °C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop panels | E1-grade melamine-faced particleboard | |
|---|---|---|
| Pedestal drawer fronts | Two-tone white and navy blue melamine finish | |
| Edge protection | 2mm thick impact-resistant PVC edge banding | |
| Under-desk support frame | 1.5mm thick powder-coated cold-rolled steel square tubing | |
| Privacy divider frames | Black-finish aluminum alloy extrusion | |
| Divider infill panels | Lower melamine panel, upper translucent perforated panel | |
| Drawer hardware | Zinc-plated steel ball-bearing slides, curved metal pull handles | |
| Adjustable feet | Nylon and steel height-adjustable glides | |
| Included task chair frames | Glass-filled nylon back and arm supports, chrome-plated steel 5-star bases | |
| Chair seating surfaces | Breathable mesh backrest, upholstered fabric seat cushion | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Privacy separation | Cross-mounted dividers separate four individual work zones | |
|---|---|---|
| Storage configuration | One fixed 3-drawer pedestal per seat at outer worktop end | |
| Cable management | One 60mm cable grommet per worktop with under-desk cable routing | |
| Desk leveling | Adjustable nylon glides at all support points | |
| Chair mobility | 50mm diameter nylon twin casters on each chair base | |
| Chair adjustment | Gas-lift seat height adjustment lever under each seat | |
| Modular assembly | Knock-down panel and frame construction | |
| CPU storage space | Open shelf under each work surface between pedestal and central frame | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff zones | Four dedicated private work positions for shared office floors | |
|---|---|---|
| Small business administrative areas | Built-in storage reduces need for additional separate filing cabinets | |
| Corporate back-office departments | Wear-resistant surfaces support daily computer and paperwork tasks | |
| Call center and shared work hubs | Dividers reduce acoustic and visual distraction for focused task work | |
| Government and public institution offices | Standardized dimensions meet standard commercial office fit-out requirements | |
| Office renovation and fit-out projects | Modular design allows easy reconfiguration with additional cluster units |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and safety requirements | |
| EN 1335-1:2020 | Office chairs dimensional safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | Office chairs general purpose performance standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks and workstations | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 10357.1-2013 | Mechanical test methods for furniture desks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3327-2017: Performance requirements for office desks and workstations; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 10357.1-2013: Mechanical test methods for furniture desks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
