PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1500 × 1400 × 1200 mm
Overall footprint (L x W x total H)	1500 x 1400 x 1200 mm
Work surface height from floor	750 mm
Work surface panel thickness	25 mm
Partition panel thickness	83 mm
Aluminum partition frame profile thickness	1.5 mm
Knee well clearance height under desktop	680 mm
Mobile under-desk pedestal dimensions (W x D x H)	445 x 505 x 580 mm
Lower solid fabric partition panel height	900 mm
Upper ventilated slat partition panel height	300 mm
Work surface short-side depth	600 mm
Work surface long-side width	1400 mm
Partition base leveler adjustment range	15 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Complete set total weight	75 kg
Work surface static load capacity	120 kg
Recommended user weight capacity	136 kg
Melamine surface wear resistance	2000 cycles
Fabric partition panel acoustic attenuation	18 dB
Drawer slide cycle durability	50000 cycles
Available standard color options	60
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface substrate	25mm thick E1 grade melamine-faced chipboard
Work surface edge banding	2mm thick PVC edge trim
Partition frame structure	1.5mm thick anodized silver aluminum alloy extrusions
Lower partition panels	Fabric-wrapped tackable medium density fiberboard core
Upper partition panels	Ventilated slatted aluminum grille with horizontal trim
Mobile pedestal body	0.8mm thick cold-rolled steel with powder coat finish
Pedestal drawer lock	Zinc alloy cam lock with 2 keys per unit
Pedestal mobility components	50mm diameter nylon swivel casters, 2 with brake locks
Partition base levelers	Reinforced nylon adjustable feet with steel threaded stems
Modular connection hardware	Zinc-plated steel bracket and screw assembly
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

3-sided privacy divider system	Encloses single L-shaped workstation to reduce visual and acoustic distraction
Mobile under-desk pedestal storage	Rolls out for access, locks to secure documents and office supplies, fits fully under desk
Floor leveler adjustment	Rotating feet adjust to correct uneven floors and stabilize partition frames
Upper slat panel ventilation	Allows air circulation across cubicles while maintaining line-of-sight privacy
Knock-down modular assembly	Panels and desktop connect with standardized hardware for reconfiguration or relocation
Tackable fabric partition surface	Lower fabric panels accept push pins for posting notes or documents
Pedestal caster brake function	Two lockable casters prevent unintended pedestal movement when in use
Surface stain resistance	Melamine desktop resists water, coffee, and common office stains for easy cleaning
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office space	Creates individual private workstations to reduce distraction in large open offices
Call center operations	Acoustic fabric panels and compact layout support focused phone-based work
Small business admin areas	Modular single-seat design fits small office footprints with dedicated storage
Co-working shared offices	Reconfigurable modular construction supports flexible seating plan changes
Administrative staff work areas	Ergonomic 750mm desk height and knee clearance suit full-day seated work
Temporary project team offices	Knock-down design allows fast installation and reconfiguration for short-term teams

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office worktables safety and performance requirements for work surface dimensions and stability
EN 527-2:2002+A1:2019	Mechanical safety requirements for office desks including load and durability testing
EN 13986:2004+A1:2015	Performance specifications for wood-based panels used in office furniture construction

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	Safety and performance standard for office desks, including load and stability tests
ANSI/BIFMA X5.3-2019	Performance standard for office vertical files and mobile storage pedestals
ANSI/BIFMA X5.9-2019	Storage furniture performance standard for drawer durability and lock function

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden office furniture, applicable to worktop and panel components
GB/T 3327-2016	Performance requirements for office desks and workstations for height and load testing
GB 18580-2017	Formaldehyde emission limits for wood-based panels used in indoor office furniture
GB/T 10357.1-2013	Furniture mechanical performance test methods for table static load and durability

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and panel components;
2. GB/T 3327-2016: Performance requirements for office desks and workstations for height and load testing;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels used in indoor office furniture;
4. GB/T 10357.1-2013: Furniture mechanical performance test methods for table static load and durability;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CUB-L1-1500-WM

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CUB-L1-1500-WM

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CUB-L1-1500-WMOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Single-Seat L-Shaped Office Cubicle Workstation Desk (model CUB-L1500-WM) is an unbranded modular workspace solution engineered for individual focused work across commercial office environments. Its L-shaped layout occupies a 1500 x 1400 x 1200 mm footprint, with a 750 mm high work surface set to support full-day seated use, paired with 680 mm of knee well clearance to accommodate standard office seating. The 3-sided partition system pairs 900 mm high lower fabric-wrapped tackable panels with upper ventilated slatted aluminum grilles, framed by 1.5 mm thick anodized silver aluminum extrusions; the upper slats preserve line-of-sight privacy while enabling cross-cubicle air circulation, and the 83 mm thick partitions deliver 18 dB of acoustic attenuation to cut distracting background noise. The worktop is constructed from 25 mm thick E1 grade melamine-faced chipboard, finished with 2 mm thick PVC edge trim for durable daily use, rated to support 120 kg of static load with a melamine surface tested to withstand 2000 wear cycles. The included under-desk mobile pedestal is built from 0.8 mm thick powder-coated cold-rolled steel, measuring 445 x 505 x 580 mm to tuck fully beneath the work surface. It rides on 50 mm diameter nylon swivel casters, two of which feature brake locks to prevent unintended movement, and is secured by a zinc alloy cam lock with two included keys to protect stored documents and supplies; its drawer slides are rated for 50000 open-close cycles for long-term reliability. The cubicle rests on reinforced nylon adjustable feet with steel threaded stems to correct uneven flooring and stabilize the full partition structure. The lower fabric panel surfaces accept push pins for posting notes, reference materials, or reminders. The knock-down modular design uses standardized connecting hardware to support easy reconfiguration or relocation, with 60 available standard color options to align with existing office decor. This workstation is well suited for open plan offices, call center operations, small business admin areas, co-working shared spaces, permanent administrative staff zones, and temporary project team offices, where its compact footprint balances personal privacy and efficient space use. When planning procurement, note that each unit ships in two cartons with a total packaged gross weight of 120 kg and 0.8 m³ packaging volume, requires 40 minutes of assembly time per set, and has a recommended user weight capacity of 136 kg. The modular build allows teams to scale installations incrementally and adjust seating layouts as operational needs shift.

Single-Seat L-Shaped Office Cubicle Workstation Desk Specifications
