2-Person Linear Modular Office Cubicle Workstation with Slatted Privacy Panels (model CUB-2P-LIN-1050H) is listed under L-Shaped Office Desk, with overall dimensions of 3760 × 1880 × 1050 mm and main material of Particle‑board (PB). Load capacity: 113 kg. Certifications: Light,grey,finish,silver,metal,frame,slatted,translucent,upper,panels,solid,lower,modesty,integrated,cable,grommets. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 3760 x 1880 x 1050 mm | |
|---|---|---|
| Individual work surface height | 750 mm | |
| Single work surface dimensions | 1820 x 610 mm | |
| Seated knee clearance height under desk | 673 mm | |
| Privacy partition panel total height | 1050 mm | |
| Privacy partition panel thickness | 41 mm | |
| Desktop thickness | 25 mm | |
| Cable grommet diameter per desktop | 60 mm | |
| Desk support leg cross-section | 45 x 45 mm square | |
| Modesty panel height | 420 mm | |
| Slatted upper panel section height | 380 mm | |
| Adjustable leveling foot adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Uniform static load per desktop | 113 kg | |
|---|---|---|
| Total unit net weight | 283 kg | |
| Seating capacity per workstation unit | 2 people | |
| Partition frame static load capacity for accessories | 15 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Leveling foot maximum floor gap compensation | 15 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface substrate and finish | 25mm particleboard core with thermally fused light grey laminate top, 2mm PVC edge banding | |
|---|---|---|
| Partition frame structure | Anodized silver aluminum extruded profile frames with steel connecting brackets | |
| Lower privacy/modesty panels | 18mm composite MDF core with matte light grey melamine finish, dark grey accent trim | |
| Upper slatted privacy section | Translucent horizontal rigid slats set in aluminum frame, partial visual/light pass-through | |
| Desk support legs | Powder-coated square steel tube with integrated threaded leveling feet | |
| Cable management grommets | Injection-molded ABS plastic grommet with removable cap, black finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable routing system | Rear desktop grommets route power/data cables from surface to under-desk wire channels | |
|---|---|---|
| Floor leveling adjustment | Threaded adjustable feet at each support post allow 15mm height adjustment to level stations on uneven floors | |
| Modular panel connection | Bolt-on aluminum bracket connectors allow reconfiguration to add/remove workstations | |
| Seated visual privacy | 1050mm tall partitions block direct line of sight between adjacent seated users |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff seating zones | Provides defined individual workspaces with partial privacy for dense open office layouts | |
|---|---|---|
| Administrative and back-office work areas | Suitable for task-based roles requiring desktop space and cable management for computer equipment |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to desk performance | |
|---|---|---|
| EN 1335-1:2000 | Office furniture office chairs dimensional safety, coordinated for seated work clearance | |
| EN 1022:2018 | Furniture seating stability, coordinated for compatible chair use at stations |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for desktop load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.6-2020 | Panel systems performance standard, applicable to partition structural integrity |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate desktop and panel components | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable to work surface strength and dimensional stability | |
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, applicable for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate desktop and panel components; 2. GB/T 3327-2016: Technical requirements for office desks, applicable to work surface strength and dimensional stability; 3. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, applicable for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
