Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Per-seat recommended weight capacity | 150 kg | |
| Total workstation net weight | 320 kg | |
| User capacity | 6 people | |
| Adjustable foot height adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 25mm thick melamine-faced particleboard, wear-resistant, scratch-resistant, easy to clean | |
|---|---|---|
| Partition fabric panel | Medium density fiberboard core with woven polyester fabric upholstery, sound-absorbing | |
| Partition frame | Anodized aluminum alloy extrusion profile, silver matte finish, corrosion-resistant | |
| Upper partition slats | Frosted translucent acrylic slats, semi-transparent for light transmission | |
| Under-desk support | 1.2mm thick cold-rolled steel frame, epoxy powder coated grey finish | |
| Pedestal cabinet | 18mm thick melamine particleboard with lockable door, matching desktop finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Desktop cable grommets route wiring to under-desk horizontal cable trays, hidden from view | |
|---|---|---|
| Floor leveling system | Adjustable plastic feet at each support leg, compensates for 15mm floor unevenness | |
| Modular connection system | Aluminum profile connectors allow panel reconfiguration and expansion of workstation clusters | |
| Under-desk storage | Lockable fixed pedestal per seat provides enclosed storage for personal items and documents |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office areas | Provides divided semi-private workspaces for 6 employees while maintaining team visibility | |
|---|---|---|
| Call centers and administrative departments | Standardized cubicle layout supports consistent workspace allocation and easy expansion |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
