Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Total workstation net weight | 65 kg | |
| Recommended maximum user weight | 110 kg | |
| Partition frame lateral stability load | 20 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop core | 18mm thick E1 grade particleboard | |
|---|---|---|
| Desktop surface | 0.6mm thick wear-resistant melamine laminate | |
| Partition frame | 1.2mm thick extruded aluminum alloy | |
| Lower partition panel | 12mm thick MDF core with dark green fabric wrap | |
| Upper partition section | 3mm thick frosted polycarbonate louvers | |
| Pedestal drawer fronts | 16mm thick melamine faced particleboard |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Keyboard tray operation | Smooth ball-bearing pull-out tray, slides 300mm from desk front | |
|---|---|---|
| Pedestal mobility | 4 swivel casters allow pedestal to move freely under desk or to adjacent positions | |
| Integrated cable management | Round desktop grommet routes cables to under-desk power strip mounting plate | |
| Integrated power access | Under-desk mounting plate fits standard power outlets, network ports and USB chargers |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Provides individual work zones with balanced privacy and collaborative visibility for corporate offices | |
|---|---|---|
| Small business and startup work areas | Compact single-seat layout fits space-constrained offices with limited floor area |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
