Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 4200 x 4200 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Partition screen total height | 1200 mm | |
| Individual L-shaped workstation footprint | 1400 x 1400 mm | |
| Work surface depth | 750 mm | |
| Work surface thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Seated knee clearance height | 680 mm | |
| Mobile pedestal dimensions | 420 x 460 x 650 mm | |
| Cable grommet diameter | 60 mm | |
| Lower solid privacy panel height | 800 mm | |
| Upper slatted vent panel height | 400 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total system net weight | 420 kg | |
|---|---|---|
| Work surface static load capacity | 100 kg | |
| Maximum supported users | 6 | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface stain and abrasion resistance | 2000 cycles | |
| Mobile pedestal caster static load | 50 kg per caster | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm E1 grade melamine-faced particleboard | |
|---|---|---|
| Desk edge banding | 2mm thick impact-resistant PVC | |
| Partition frame | Powder-coated extruded aluminum alloy | |
| Lower partition panel | Fabric-wrapped MDF core | |
| Upper partition panel | Powder-coated steel slatted grille | |
| Desk support frame | 1.5mm thick powder-coated square steel tubing | |
| Mobile pedestal body | 18mm thick melamine-faced engineered wood | |
| Drawer hardware | Three-section double-ball bearing steel slides | |
| Casters | 50mm diameter nylon swivel casters with brakes | |
| Hardware fasteners | Zinc-plated steel connector bolts and cam locks | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Partition privacy separation | Fabric and slat dividers separate 6 individual work zones | |
|---|---|---|
| Per-seat lockable storage | One lockable drawer and one storage compartment per mobile pedestal | |
| Cable management | Round desk grommet at each work surface routes power/data cords | |
| Mobile pedestal mobility | Pedestals roll on 4 swivel casters with two lock positions | |
| Modular reconfiguration | Panel-mounted aluminum frame supports layout modification | |
| Curved corner work surface | Ergonomic curved front edge on corner positions | |
| Full-extension drawer access | Double-ball slides allow 100% drawer extension | |
| Freestanding assembly | Modular panels connect without permanent floor fixing | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan corporate offices | Cross layout clusters 6 staff efficiently with dedicated work and storage space | |
|---|---|---|
| Call center and customer service floors | Privacy partitions reduce cross-talk distraction between adjacent agents | |
| Startup and coworking spaces | Modular construction allows reconfiguration as team size changes over time | |
| Back office and administrative departments | Per-seat lockable storage secures files and personal work materials | |
| Finance and accounting team zones | Stain-resistant melamine surfaces support daily paperwork and device use | |
| Staff training and temporary project teams | Knockdown assembly allows rapid deployment and relocation between floors | |
| Open-plan government and public sector workspaces | Neutral two-tone finish matches standard professional office decor |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables dimensional and safety requirements for work surface height and strength | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic clearance standards for seated knee space | |
| EN 14073-2:2004 | Office storage furniture safety requirements for mobile pedestals and drawers | |
| EN 12720:2009 | Surface resistance to cold liquids for melamine finished work surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for mobile pedestal drawer and caster testing | |
| ANSI/BIFMA X7.1-2021 | Formaldehyde emission standard for composite wood used in office furniture | |
| ANSI/BIFMA M7.1-2021 | Office furniture emissions testing for volatile organic compound limits |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktops and cabinet components | |
|---|---|---|
| GB/T 3327-2016 | Office desk performance and dimensional stability standards for work surfaces | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood panels used in desk and pedestal construction | |
| GB/T 4897.3-2003 | Particleboard specifications for structural and surface-use furniture panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktops and cabinet components; 2. GB/T 3327-2016: Office desk performance and dimensional stability standards for work surfaces; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood panels used in desk and pedestal construction; 4. GB/T 4897.3-2003: Particleboard specifications for structural and surface-use furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
