Automatic mm / inch conversion · Core engineering specifications
| overall footprint diameter | 3600 x 3600 x 1200 mm | |
|---|---|---|
| per-seat L-shaped worktop dimensions | 1400 x 1400 mm | |
| work surface height | 750 mm | |
| partition panel height above floor | 1200 mm | |
| partition panel thickness | 18 mm | |
| worktop thickness | 25 mm | |
| under-desk knee clearance height | 680 mm | |
| knee clearance depth under work surface | 600 mm | |
| mobile pedestal dimensions per station | 400 x 500 x 600 mm | |
| pedestal caster diameter | 50 mm | |
| curved inner work edge radius | 300 mm | |
| partition metal frame tubing diameter | 20 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| total system gross weight | 220 kg | |
|---|---|---|
| per worktop static load capacity | 300 kg | |
| seating capacity | 3 persons | |
| product warranty period | 5 years | |
| worktop surface scratch resistance rating | 2000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| worktop substrate | 25mm melamine-faced particleboard (MFC) | |
|---|---|---|
| partition panel core | 18mm medium density fiberboard | |
| partition frame finish | Powder-coated white steel tubing | |
| mobile pedestal carcass | 18mm melamine-laminated engineered wood | |
| pedestal casters | Black nylon swivel casters | |
| pedestal drawer handle/latch | Black recessed plastic pull with integrated lock | |
| modular connection hardware | Zinc-plated steel cam-lock bolts and brackets | |
| edge banding on worktops | 2mm thick PVC edge trim | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| modular cluster layout | 120-degree angled 3-station curved arrangement | |
|---|---|---|
| partition privacy function | 1200mm high fabric dividers | |
| mobile pedestal storage per station | 1 lockable drawer + 1 door-enclosed cabinet | |
| caster mobility for pedestals | 360-degree swivel casters on each pedestal | |
| knock-down assembly system | Cam-lock connected modular components | |
| work surface cable management | Recessed cable port at corner of each work position | |
| under-desk knee access | Curved inner work edge with 680mm vertical clearance | |
| surface cleanability | Smooth melamine laminate finish | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| largest single carton dimensions | 1500 x 1500 x 100 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Suitable for 3 administrative/operational staff with partial acoustic and visual privacy | |
|---|---|---|
| Small business open work zones | Space-efficient 3-person cluster fits compact footprints without separate private offices | |
| Co-working space dedicated work zones | Standardized individual work positions with personal under-desk storage for members | |
| Back-of-house office support zones | Durable construction for high daily use in administrative and processing departments | |
| Startup office collaborative spaces | Balanced privacy and open feel supporting team interaction between adjacent positions | |
| Corporate call center stations | Partitioned layout reduces visual distraction for focused screen and phone work | |
| Government agency service office zones | Durable, easy-clean finish suitable for high-traffic public sector office environments |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety, strength and durability requirements | |
|---|---|---|
| EN 1335-1:2020 | Office furniture dimensional coordination for seated work positions | |
| EN 14073-2:2004 | Office storage furniture strength and stability requirements | |
| EN 71-3:2019 | Migration of certain elements limit for furniture surface materials |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety, durability and structural performance standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Office storage units performance and structural integrity standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktops and storage units | |
|---|---|---|
| GB/T 3327-2016 | Office desk dimensional, structural and durability requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels used in interior furniture | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture-grade structural use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktops and storage units; 2. GB/T 3327-2016: Office desk dimensional, structural and durability requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels used in interior furniture; 4. GB/T 4897.3-2003: Particleboard specifications for furniture-grade structural use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
