Product supplier2-Person Face-to-Face Office Cubicle Workstation with Integrated Storage Pedestals, 25mm E1-grade melamine-faced chipboard with PVC edge banding
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1200 × 1220 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Per-user work surface size | 1200 x 600 mm | |
| Privacy partition height above floor | 1220 mm | |
| Integrated storage pedestal dimensions | 400 x 500 x 650 mm | |
| Knee clearance height under work surface | 620 mm | |
| Knee clearance width per seat | 700 mm | |
| Work surface thickness | 25 mm | |
| Drawer front accent panel height | 150 mm | |
| Support leg height | 120 mm | |
| Central divider panel width | 30 mm | |
| Lower cabinet door height | 500 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total work surface static load capacity | 200 kg | |
|---|---|---|
| Product net weight | 85 kg | |
| Recommended user capacity | 2 people | |
| Surface abrasion resistance | 2000 cycles | |
| Surface water and stain resistance | Pass | |
| Commercial product warranty | 5 years | |
| Available color finish options | 4 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1-grade melamine-faced chipboard with PVC edge banding | |
|---|---|---|
| Back privacy panels | Sage green woven fabric upholstery over particleboard core with dark steel framing | |
| Central divider insert | Horizontal slatted light-toned infill with dark steel frame | |
| Upper drawer fronts | Sage green matte melamine finish with integrated key lock | |
| Lower cabinet doors | Light washed oak-effect fluted melamine finish | |
| Support legs and frame | 1.2mm thick powder-coated dark gray tapered steel tubing | |
| Drawer slides | Three-section full-extension ball-bearing steel slides | |
| Cabinet core material | 18mm E1-grade melamine-faced particleboard | |
| Locks | Keyed-alike cam locks for upper drawer per workstation | |
| Leveling feet | Nylon-tipped adjustable steel glides at leg base | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Visual privacy partition | Blocks direct line of sight between seated users, 1220mm total height | |
|---|---|---|
| Per-user lockable storage | One lockable upper drawer and one lower enclosed cabinet per seat | |
| Cable management access | One 60mm cable grommet per work surface near partition edge | |
| Knee clearance access | Open central recess at each seat allows full task chair push-in | |
| Leveling adjustment | Adjustable glides compensate for 15mm of uneven floor height | |
| Storage drawer operation | Full-extension ball-bearing slides allow full access to drawer contents | |
| Modular configuration | Panels connect via steel bracket system to allow reconfiguration | |
| Surface maintenance | Stain-resistant melamine surface allows cleaning with standard office disinfectants | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Provides individual privacy for clerical, administrative or call center staff | |
|---|---|---|
| Co-working shared offices | Modular two-seat layout supports flexible dedicated desk assignments | |
| Small business back offices | Integrated storage eliminates need for separate filing cabinets per user | |
| Administrative work areas | Standard 760mm work height suits all standard office task chairs | |
| Startup office fit-outs | Light wood and sage green finish delivers modern, low-clutter aesthetic | |
| Call center work floors | High partitions reduce visual distraction between adjacent agents |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and dimensional requirements, applicable for work height and clearance | |
|---|---|---|
| EN 527-2:2019 | Office worktables mechanical safety and stability requirements, applicable for load testing | |
| EN 13986:2004 | Wood-based panels formaldehyde emission for construction use, applicable for panel material checks |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for commercial duty load and durability tests | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emissions and indoor air quality |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for desk structural stability | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for engineered wood panels, applicable for board material acceptance | |
| GB/T 10357.1-2013 | Desk strength and durability test standard, applicable for surface and frame load testing |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for desk structural stability; 2. GB 18580-2017: Formaldehyde emission limits for engineered wood panels, applicable for board material acceptance; 3. GB/T 10357.1-2013: Desk strength and durability test standard, applicable for surface and frame load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
