Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (2-station set) | 2800 x 2400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Work surface length per side | 1800 mm | |
| Work surface depth per side | 750 mm | |
| Partition panel thickness | 60 mm | |
| Partition overall height | 1200 mm | |
| Slotted transom height | 200 mm | |
| Seated knee clearance height | 680 mm | |
| Knee clearance width per station | 800 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Caster diameter for mobile pedestals | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set net weight | 260 kg | |
|---|---|---|
| Work surface static load capacity | 150 kg | |
| Drawer static load per drawer | 25 kg | |
| Recommended user count | 2 users | |
| Leveling glide adjustment range | 15 mm | |
| Standard commercial warranty | 5 years | |
| Available finish color count | 30 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | E1-grade melamine-faced particleboard (MFC) with 2mm PVC edge banding | |
|---|---|---|
| Partition frame | Powder-coated aluminum extrusion | |
| Partition lower panel | Fabric-wrapped medium density fiberboard core | |
| Partition upper transom | Slotted polycarbonate louver panel in aluminum frame | |
| Structural support legs | Powder-coated rectangular steel tubing | |
| Mobile pedestal carcass | 0.8mm thick cold-rolled steel with powder-coated finish | |
| Drawer slides | Full-extension steel ball-bearing slides | |
| Pedestal casters | Black nylon twin-wheel casters, two with locking brake | |
| Cable management grommets | ABS plastic desk grommets | |
| Leveling feet | Nylon base adjustable steel glides | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Dual workstation layout | Two adjacent curved L-shaped work zones separated by partial-height partitions | |
|---|---|---|
| Mobile pedestal storage | Lockable 3-drawer rolling pedestal fits under each work surface | |
| Privacy partition function | 1200mm high panels block seated sightlines between adjacent workstations | |
| Cable management | Desktop grommets route monitor/laptop power and data cables under the work surface | |
| Modular reconfiguration | Bolt-together panel and frame system allows layout adjustment | |
| Floor leveling | Adjustable glides on all support feet correct uneven floor surfaces | |
| Fabric tack surface | Partition fabric panels support pinned notes and documents | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan corporate offices | Provides semi-private workspaces for staff in high-density open offices | |
|---|---|---|
| Coworking shared office spaces | Modular configuration fits flexible hot-desking or dedicated seat layouts | |
| Call center and admin departments | Partial dividers reduce cross-talk distraction for focused task work | |
| Small business office interiors | Compact two-person footprint fits small team offices with storage needs | |
| Government and public sector work areas | Durable commercial construction meets long-term heavy use requirements | |
| Project team zones | Clustered workstation layout supports adjacent collaborative small teams |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for desk structures | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic dimensions for seated work surfaces | |
| EN 1022:2018 | Furniture seating and desk stability test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load, durability and stability | |
|---|---|---|
| ANSI/BIFMA X5.6-2016 | Panel systems performance standard for modular office partitions | |
| ANSI/BIFMA X5.3-2020 | Vertical and lateral filing cabinet performance for mobile pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to MFC work surfaces | |
|---|---|---|
| GB/T 3327-2017 | Office furniture desk performance requirements for load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels used in indoor furniture | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture grade structural panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to MFC work surfaces; 2. GB/T 3327-2017: Office furniture desk performance requirements for load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels used in indoor furniture; 4. GB/T 4897.3-2003: Particleboard specifications for furniture grade structural panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
