PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1800 × 1460 × 990 mm
Overall unit dimensions	1800 x 1460 x 990 mm
Individual seat center-to-center width	590 mm
Seat height above finished floor	440 mm
Seat cushion usable depth	485 mm
Seat cushion usable width	480 mm
Backrest total height from seat surface	550 mm
Integrated writing tablet dimensions	450 x 300 x 18 mm
Floor mounting footplate dimensions	220 x 120 mm
Frame leg tube cross-section	80 x 40 mm
Writing tablet height above seat surface	260 mm
Knee clearance under writing tablet	200 mm
Side end panel thickness	20 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total 6-seat unit static load capacity	900 kg
Single individual seat static load rating	150 kg
Seat cushion foam density	60 kg/m³
Backrest foam density	60 kg/m³
Seat cushion foam thickness	140 mm
Backrest foam thickness	120 mm
Upholstery fabric abrasion resistance	50000 Martindale cycles
Powder-coated frame corrosion resistance	500 hours salt spray
Net weight per individual seat	18 kg
Reference Static Load	150 kg depending on category

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Structural frame	2.5 mm thick cold-rolled steel with electrostatic powder coating
Seat internal support panel	15 mm thick 7-layer hardwood plywood
Backrest internal support panel	15 mm thick 7-layer hardwood plywood
Upholstery fabric	Flame-retardant, stain-resistant woven public seating fabric
Writing tablet core and surface	18 mm MDF core with fire-resistant melamine laminate, PU edge banding
Side end panels	2 mm thick molded PP composite with two-tone grey/white finish
Floor mounting hardware	Galvanized steel expansion anchor bolts
Seat mechanism hardware	Powder-coated steel torsion spring return assembly
Tablet support brackets	Die-cast aluminum alloy with anti-rust finish
Edge trim components	Soft PVC rounded edge trim on tablet and panel edges
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat cushion return function	Silent torsion-spring automatic tip-up return when unoccupied
Floor-fixed installation	Permanent anchoring via expansion bolts to concrete finished floors
Integrated writing surface	Fixed shared tablet positioned between opposing seat pairs for note-taking or device placement
Modular row expansion	Connectable modular units allow variable row lengths for custom waiting area layouts
Seating separation	Individual divided seat cushions and backrests define personal seating space
Easy-clean surfaces	Smooth powder-coated frame and non-porous laminate tablets allow wipe-down cleaning
Anti-tip structural design	Wide flared floor footplates distribute load across floor surface
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Transit terminal waiting areas	Suitable for airport, railway, and bus station waiting zones with high passenger turnover
Public service hall waiting zones	Appropriate for government office, hospital, and bank waiting areas
Educational institution exam/waiting zones	Suitable for campus registration, examination waiting, and student service areas
Indoor public concourse seating	Designed for permanent indoor installation in covered public concourses
High-capacity waiting layouts	Back-to-back layout maximizes seating density without sacrificing user personal space

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 13761:2002	Public seating furniture – Performance requirements for general public use
EN 1022:2018	Furniture – Seating – Determination of stability, applicable to fixed units
EN 13501-1:2018	Fire classification of construction products for upholstered public furniture

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	General purpose office chairs – Strength and durability reference for seated loads
ANSI/BIFMA X6.1-2018	Educational seating – Reference for integrated writing surface performance

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for metal furniture, applicable to steel frame structure
GB 20286-2006	Flame retardant requirements for public place furniture upholstery components
GB/T 10357.3-2013	Furniture mechanical performance test for chair and stool strength and durability
GB/T 35607-2017	Limit of harmful substances in upholstered furniture for indoor use

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to steel frame structure;
2. GB 20286-2006: Flame retardant requirements for public place furniture upholstery components;
3. GB/T 10357.3-2013: Furniture mechanical performance test for chair and stool strength and durability;
4. GB/T 35607-2017: Limit of harmful substances in upholstered furniture for indoor use;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · PWB-BB6-WT-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · PWB-BB6-WT-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · PWB-BB6-WT-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The PWB-BB6-WT-001 unbranded back-to-back 6-seat floor-fixed public waiting bench delivers a high-density, user-centric seating solution for busy indoor public spaces, configured to balance seating capacity with clear personal space boundaries. Its symmetrical back-to-back layout anchors three seat positions along each side of a central structural spine, with two-tone grey and white molded PP composite side panels framing the unit for a streamlined, modern visual profile. Wide, flared floor mounting footplates anchor the structure firmly, while distinct, divided seat and backrest cushions create clearly demarcated personal seating zones to reduce user crowding, with fixed integrated writing tablets positioned between opposing seat pairs for shared, convenient access. The bench is built for consistent long-term use in high-footfall environments, starting with a 2.5mm thick cold-rolled steel frame finished with durable electrostatic powder coating. Internal seat and backrest supports use 15mm thick 7-layer hardwood plywood, topped with 60kg/m³ density PU foam cushions: 140mm thick for seats, 120mm thick for backrests, upholstered in flame-retardant, stain-resistant woven public seating fabric rated for 50000 Martindale abrasion cycles. Writing tablets feature an 18mm MDF core with fire-resistant melamine laminate and PU edge banding, supported by anti-rust finished die-cast aluminum alloy brackets. The unit uses galvanized steel expansion anchor bolts for permanent concrete floor installation, paired with powder-coated steel torsion spring assemblies for silent, automatic tip-up seat return when seats are unoccupied. It carries a total static load capacity of 900kg, with each individual seat rated for 150kg of static load. Functional design elements support smooth daily operation: the automatic seat return keeps aisles clear when not in use, non-porous laminate tablets and smooth powder-coated frames allow quick wipe-down cleaning, and connectable modular units support custom row lengths to fit unique space layouts. The anti-tip structural design adds stability for high-traffic use, and integrated tablets provide a stable surface for note-taking or placing personal mobile devices. This bench is suited for transit terminal waiting areas including airports, railway stations and bus stations, public service halls such as government offices, hospitals and banks, and educational institution zones for registration, exam waiting and student services, as well as permanent covered indoor public concourses. For procurement, note the unit requires permanent anchoring to finished concrete floors, with 40 minutes of assembly time per set delivered across two cartons with a total packaged gross weight of 120kg. Modular connectivity allows teams to scale seating to match required capacity for specific waiting area footprints. The back-to-back configuration maximizes seating density without compromising personal space, making it ideal for high-capacity waiting layouts that require durable, low-maintenance seating with accessible work surfaces.

Back-to-back 6-seat floor-fixed public waiting bench with integrated writing tablets Specifications
