Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (table plus two nested chairs) | 2000 x 700 x 820 mm | |
|---|---|---|
| Tabletop overall dimensions | 1400 x 500 x 25 mm | |
| Standard work surface height | 750 mm | |
| Under-table knee clearance height | 680 mm | |
| Under-table knee clearance width between legs | 1100 mm | |
| Perforated modesty panel dimensions | 1100 x 250 mm | |
| Under-table wire basket dimensions | 250 x 150 x 100 mm | |
| T-leg base footprint per side | 500 x 60 mm | |
| Single chair seat height | 450 mm | |
| Single chair overall dimensions | 480 x 520 x 820 mm | |
| Chair seat depth | 420 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Table static uniform load capacity | 320 kg | |
|---|---|---|
| Table net weight | 30 kg | |
| Chair stackability count | 10 chairs | |
| Tabletop scratch resistance rating | 2000 cycles | |
| Powder-coated frame salt spray resistance | 48 hours | |
| Maximum vertical chair stack count | 10 chairs | |
| Tabletop laminate abrasion resistance | 2000 cycles | |
| Floor glide vertical load rating per unit | 80 kg | |
| Flip mechanism cycle durability | 10000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm high-density particleboard core | |
|---|---|---|
| Tabletop surface finish | 0.6mm light oak melamine laminate, wear-resistant | |
| Table edge banding | 1.5mm black PVC T-molding | |
| Table frame and legs | 1.2mm thick black powder-coated square steel tubing | |
| Modesty panel | 1.0mm perforated black powder-coated steel | |
| Floor glides | Nylon non-marking adjustable glides | |
| Chair seat and back | 12mm bent laminated birch plywood with natural oak veneer | |
| Chair frame | 15mm diameter black powder-coated steel sled legs | |
| Chair seat and back shells | 12mm bent laminated birch plywood with natural oak veneer | |
| Chair support frame | 18mm diameter black powder-coated steel X-sled legs | |
| Flip release hardware | Zinc-plated steel lever and pivot assembly | |
| Under-table storage basket | 4mm diameter black powder-coated steel wire |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop flip mechanism | Dual-side lever release, flips 90 degrees vertical for nesting | |
|---|---|---|
| Nesting storage spacing | Nested tables require 150mm depth per unit | |
| Modesty panel function | Blocks leg visibility for seated users across the long table edge | |
| Under-table wire basket | Holds power adapters, cables and small training materials | |
| Chair stacking function | Sled-base design allows vertical stacking without disassembly | |
| Floor glide adjustment | 10mm height adjustment per glide to level on uneven floors | |
| Cable management access | Open gap between modesty panel and tabletop for cable routing | |
| Nested table alignment | Integrated side glides allow straight nested rows without scratching | |
| Cable routing access | 50mm open gap between modesty panel and tabletop for horizontal cable runs | |
| Chair carry handle | Reinforced top-back cutout allows single-hand lifting and repositioning | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Corporate training rooms | Configurable in straight rows for 2-person seated training sessions with space-efficient nesting storage | |
|---|---|---|
| Higher education seminar spaces | Quickly reconfigurable for group work, lectures or exam seating layouts | |
| Temporary conference pop-up spaces | Rapidly deployed and stacked away for multi-use room flexibility | |
| Co-working shared meeting areas | Lightweight, repositionable set for ad-hoc small group meetings | |
| Staff onboarding rooms | Durable easy-clean surfaces for high-turnover daily training use | |
| Community center event spaces | Stackable chairs and nested tables enable fast room turnover for public events | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2007 | Office work tables: safety, strength and durability requirements | |
|---|---|---|
| EN 1335-2:2009 | Office chairs: safety requirements for non-adjustable seating | |
| EN 16139:2013 | Non-domestic seating: strength, durability and safety for contract use | |
| EN 14073-2:2004 | Office storage furniture: safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products: standard for safety and performance | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General purpose office chairs: safety and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3325-2017 | Metal office furniture strength and durability requirements | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limits for wood furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test standards for tables |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3325-2017: Metal office furniture strength and durability requirements; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limits for wood furniture; 4. GB/T 10357.1-2013: Furniture mechanical performance test standards for tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
