Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 810 × 900 × 770 mm | |
|---|---|---|
| Seat width | 680 mm | |
| Seat depth | 600 mm | |
| Seat height | 450 mm | |
| Backrest height | 380 mm | |
| Armrest height from seat | 180 mm | |
| Armrest width | 100 mm | |
| Leg height | 280 mm | |
| Back cushion dimensions | 520 x 520 x 120 mm | |
| Seat cushion thickness | 120 mm | |
| Leg diameter | 16 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 136 kg | |
|---|---|---|
| Net weight | 18 kg | |
| Seat foam density | 30 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Back cushion foam density | 25 kg/m³ | |
| Fabric abrasion resistance | 30000 double rubs | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Inner structural frame | 18mm thick engineered hardwood plywood | |
|---|---|---|
| Outer arm and back upholstery | Dark taupe matte faux leather/performance fabric | |
| Seat and back cushion upholstery | Light beige soft woven polyester fabric | |
| Cushion padding | High-density polyurethane foam | |
| Support legs | 16mm diameter matte black powder-coated carbon steel | |
| Foot glides | Non-slip injection-molded SEBS rubber caps | |
| Seat support base | 8mm thick elastic webbing suspension | |
| Stitching details | 10mm seam pitch with matching thread | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Single-person fixed lounge seating | |
|---|---|---|
| Back cushion feature | Removable loose padded back pillow for position adjustment | |
| Support structure | Four-leg fixed base with horizontal cross-brace for stability | |
| Floor protection | Non-marring rubber glides on all leg bases to prevent floor scratching | |
| Assembly requirement | Knock-down assembly required with included hardware | |
| Cleaning suitability | Spot-cleanable upholstery suitable for routine residential maintenance | |
| Armrest function | Integrated wrap-around curved armrests for lateral support and visual enclosure | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Suitable as standalone accent chair beside sofas or coffee tables for casual seating | |
|---|---|---|
| Bedroom reading nook | Appropriate for quiet lounge seating with supportive back and padded cushions | |
| Office reception and lounge areas | Suitable for visitor waiting zones with neutral two-tone professional styling | |
| Hospitality cafe and lounge spaces | Fits casual boutique cafe seating with soft curved silhouette and stable metal base | |
| Entryway foyer seating | Compact size works for temporary seating in residential or commercial entry spaces | |
| Recommended pairing | Matches light wood, neutral fabric or matte black furniture collections for coordinated interiors | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Applicable for non-domestic lounge seating strength, durability and safety | |
|---|---|---|
| EN 1021-1:2014 | Applicable for upholstered furniture cigarette ignition resistance |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
