| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Finished Seat Cushion Thickness | 90 mm | |
|---|---|---|
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single armchair static load capacity | 150 kg | |
|---|---|---|
| Single armchair net weight | 16 kg | |
| Set seating capacity | 2 persons | |
| Backrest lumbar support static load | 80 kg | |
| Upholstery abrasion resistance reference | 50000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery outer panel | Orange matte PU leather, 1.2mm thickness | |
|---|---|---|
| Seat and back upholstery inner panel | Off-white matte PU leather, 1.2mm thickness | |
| Seat cushion core | 45kg/m³ high-density polyurethane foam, 80mm thickness | |
| Backrest cushion core | 35kg/m³ high-resilience polyurethane foam, 60mm thickness | |
| Included throw pillow | Orange matte PU leather cover, 30kg/m³ filled foam core | |
| Armchair support legs | 1.2mm thick matte black carbon steel tubes | |
| Side table top | 12mm thick light gray sintered stone | |
| Side table base | 1.5mm thick carbon steel cone, orange powder coated finish | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Integrated armrest structure | Curved tub-style armrests connect seat to back, forming semi-enclosed seating for side support | |
|---|---|---|
| Fixed non-reclining backrest | Curved backrest with pre-set 105° recline angle for relaxed upright casual seating | |
| Non-slip leg configuration | Gold-tipped leg ends with integrated floor protection pads prevent hard floor scratching | |
| Fixed static seating design | No swivel, tilt or height adjustment, intended for stationary use in reception areas | |
| Stain-resistant upholstery performance | PU leather surface allows wet wiping for daily cleaning without special maintenance | |
| Stable table base design | Wide tapered conical base eliminates tipping risk when items are placed on table edges | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Suitable for visitor seating with convenient table surface for document or beverage placement | |
|---|---|---|
| Hotel lobby lounge zones | Matches modern boutique hotel decor for short-stay guest seating | |
| Residential living room accent seating | Works as paired casual seating for balcony, bedroom or small apartment living areas | |
| Cafe and tea house seating | Suitable for small two-person tables in upscale casual food service venues | |
| Beauty salon customer waiting zones | Provides comfortable, easy-to-clean seating for waiting clientele | |
| Executive office breakout spaces | Creates small informal meeting spots for short conversations between staff | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Strength, durability and safety requirements for non-domestic seating furniture | |
|---|---|---|
| EN 15372:2016 | Strength, durability and safety requirements for non-domestic tables | |
| EN 13722:2004 | Performance requirements for furniture polyurethane coated fabrics |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to wooden and upholstered general furniture | |
|---|---|---|
| GB/T 16799-2008 | Performance requirements applicable to polyurethane leather used for furniture upholstery | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to wooden and upholstered general furniture; 2. GB/T 16799-2008: Performance requirements applicable to polyurethane leather used for furniture upholstery; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
