Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 860 x 880 x 830 mm | |
|---|---|---|
| seat height | 480 mm | |
| seat width | 620 mm | |
| seat depth | 580 mm | |
| backrest height | 420 mm | |
| armrest height | 200 mm | |
| back cutout opening | 380 x 180 mm | |
| base footprint width | 800 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| net weight | 28 kg | |
|---|---|---|
| recommended static load capacity | 150 kg | |
| seat cushion foam density | 45 kg/m³ | |
| seat foam thickness | 120 mm | |
| back foam thickness | 80 mm | |
| fabric abrasion resistance | 50000 Martindale cycles | |
| floor glide load rating | 40 kg per glide | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| internal frame | 18mm thick reinforced engineered wood | |
|---|---|---|
| seat suspension | 40mm wide elastic webbing grid | |
| cushion fill | High-density polyurethane foam with polyester fiber wrap | |
| outer upholstery | Caramel brown performance faux leather | |
| seat cushion upholstery | Light cream performance fabric | |
| decorative pillow | Two-tone cream and light gray woven fabric | |
| floor contacts | 15mm diameter nylon non-marking glides | |
| seam construction | 8 stitches per 30mm seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| seating orientation | Fixed non-swivel, non-reclining position | |
|---|---|---|
| back support | Continuous wrap-around curved back with integrated armrests | |
| lumbar support | Built-in curved lower back contour | |
| base stability | Flared wide integrated upholstered base | |
| floor protection | Non-marking glides prevent floor scratches | |
| maintenance access | Removable seat cushion for easy cleaning | |
| structural cutout | Lower back rectangular cutout reduces visual weight | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| office reception areas | Pairs with small side tables for guest waiting seating | |
|---|---|---|
| lounge and break areas | Relaxed posture suitable for informal employee break spaces | |
| hotel lobby seating | Sculptural design complements modern hospitality interiors | |
| residential living rooms | Accent seating for modern living room or reading nook | |
| cafe and co-working spaces | Casual seating for customer and member lounge zones | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| seating strength stability | EN 16139:2013 | |
|---|---|---|
| upholstered furniture flammability | EN 1021:2014 |
US and Canada office-furniture standards
| lounge seating performance | ANSI/BIFMA X2022 |
|---|
Standards applicable to China-market projects
| upholstered furniture safety | GB 28007 | |
|---|---|---|
| furniture mechanical performance | GB/T 10357.3 |
This product must meet the following technical requirements: 1. upholstered furniture safety: GB 28007; 2. furniture mechanical performance: GB/T 10357.3; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
