Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 860 × 1050 × 710 mm | |
|---|---|---|
| Chair seat height | 470 mm | |
| Chair seat depth | 750 mm | |
| Chair seat width | 610 mm | |
| Chair back height | 330 mm | |
| Side table base diameter | 350 mm | |
| Side table central stem diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single chair net weight | 27 kg | |
|---|---|---|
| Single chair static weight capacity | 120 kg | |
| Side table static top load capacity | 25 kg | |
| Seating capacity per set | 2 adults | |
| Swivel mechanism cycle rating | 30000 rotations | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair upholstery fabric | Woven polyester blend, 300 gsm weight, lime green and light grey two-tone | |
|---|---|---|
| Chair seat padding | 40 mm thick high-resilience polyurethane foam, 35 kg/m³ density, 45% rebound rate | |
| Chair back padding | 30 mm thick polyurethane foam with 10 mm polyester fiber topper | |
| Chair inner frame | 1.2 mm thick powder-coated steel tube frame with corner-block joinery | |
| Chair swivel base | 2 mm thick brushed stainless steel round plinth base, fully welded | |
| Side table tabletop | 18 mm thick solid oak veneer MDF core with matte lacquer finish | |
| Side table support structure | Brushed 304 stainless steel central stem + weighted round stainless steel base | |
| Accent side detail | Matte grey circular resin button fastener on outer chair side panel | |
| Seam construction | 8 stitches per inch matching color polyester thread | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Chair swivel function | 360° frictionless rotation with automatic return to center | |
|---|---|---|
| Seat structure | Fixed-height ergonomic bucket seat with continuous curved wrap-around backrest | |
| Side table function | Static flat surface for placing beverages, reading materials, and small decor | |
| Base stability | Weighted metal table and chair bases prevent tipping during normal use | |
| Upholstery maintenance | Solvent-based cleaning code for fabric surfaces | |
| Floor protection | Non-marking felt pads pre-installed on all base bottoms | |
| Assembly requirement | Knock-down assembly requiring base attachment to chair and table frames | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception areas | Provides casual guest seating next to feature walls or entrance zones | |
|---|---|---|
| Breakout and collaboration spaces | Supports informal small group discussions or short work breaks | |
| Residential living room nooks | Creates a compact cozy seating area for reading or light refreshments | |
| Waiting room environments | Offers comfortable short-term seating for clinic, salon or co-working visitors | |
| Hotel lobby lounge zones | Complements modern interior design as modular scattered seating units | |
| Quiet study corners | Pairs with the side table to create a dedicated spot for coffee and reading | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
