Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 750 × 700 × 720 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single chair net weight | 18 kg | |
|---|---|---|
| Chair static load capacity | 150 kg | |
| Chair 360-degree swivel rotation cycle rating | 15000 cycles | |
| Upholstery fabric abrasion resistance | 50000 double rubs | |
| Cushion foam density | 35 kg/m³ | |
| Cushion foam rebound rate | 45% | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair outer upholstery | Matte velvet fabric, 1.2mm thickness | |
|---|---|---|
| Chair internal frame | Kiln-dried solid hardwood + 12mm multilayer plywood | |
| Seat cushion core | High-resilience polyurethane foam, 120mm thickness | |
| Back and armrest padding | 40mm high-density polyurethane foam | |
| Chair swivel base | Black powder-coated steel, 3mm plate thickness | |
| Side table top | 18mm high-density fiberboard, matte black lacquer finish | |
| Side table pedestal and base | Cold-rolled steel, 2mm wall thickness, gloss black baked paint finish | |
| Floor protection pads | 5mm thick non-slip felt pads, fitted to base bottoms | |
| Internal joint hardware | Zinc-plated steel screws and corner brackets | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel mechanism | Smooth bearing-based rotation without lock positions | |
|---|---|---|
| Integrated wrap-around armrest | Continuous curved structure connecting seat to backrest | |
| Low-profile armless-style cutout design | Open front arm cut for easy entry and exit | |
| Fixed non-reclining seat structure | Rigid seat-back angle of 105 degrees | |
| Side table pedestal support | Central column design leaves full leg clearance around perimeter | |
| Floor-protective fixed base | Non-marking glides on both chair and table bases | |
| Removable seat cushion (non-reversible) | Zippered fabric cover for spot cleaning access | |
| Stackable design compatibility | Non-stackable fixed upholstered form | |
| Swivel base diameter under chair | 600 mm | |
| Chair wall clearance required for rotation | 100 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room lounge areas | Pairs with sofas to create casual conversation nooks for small groups | |
|---|---|---|
| High-end hotel lobby waiting zones | Used in pairs with side tables for guest seating in reception areas | |
| Boutique office breakout spaces | Provides informal seating for short meetings or employee relaxation | |
| Coffee shop and cafe seating | Creates private two-seat zones for patrons in premium hospitality venues | |
| Residential bedroom vanity or reading corners | Functions as a standalone accent chair next to windows or dressers | |
| Showroom and model home staging | Serves as a statement accent piece to highlight modern interior design schemes | |
| Private lounge and club seating areas | Suits low-light, comfortable spaces for casual guest entertainment | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
