Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 790 x 860 x 850 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth | 580 mm | |
| Seat width | 560 mm | |
| Backrest height | 480 mm | |
| Armrest height | 220 mm | |
| Cushion thickness | 120 mm | |
| Leg diameter | 16 mm | |
| Throw pillow dimensions | 450 x 450 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 150 kg | |
|---|---|---|
| Net product weight | 19 kg | |
| Leather upholstery abrasion resistance | 70000 double rubs | |
| Fabric upholstery abrasion resistance | 20000 double rubs | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 45% | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Back and armrest upholstery | Caramel brown faux leather with stitched edge detailing | |
|---|---|---|
| Seat upholstery | Black and white houndstooth woven fabric | |
| Inner support shell | 12 mm thick bent plywood | |
| Seat cushion core | High-density polyurethane foam | |
| Leg frame | Matte black powder-coated 16mm diameter tubular steel | |
| Leg foot caps | Brass-finish metal protective floor caps | |
| Throw pillow cover | Light gray linen-blend fabric | |
| Frame finish coating | Scratch-resistant epoxy powder coating | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Single fixed-position non-reclining seat for one adult user | |
|---|---|---|
| Assembly requirement | Knock-down leg attachment with included hardware | |
| Floor protection | Brass foot caps prevent floor scratching and distribute leg weight | |
| Back support design | Contoured sloped back angled 105 degrees from seat for relaxed lounging | |
| Arm support design | Integrated wrap-around armrests forming continuous side enclosure | |
| Cleaning compatibility | W/S fabric cleaning code for mixed upholstery surfaces | |
| Stability design | Four splayed metal legs provide 700mm x 650mm stable footprint | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Use as standalone accent seating next to sofas or side tables for guest seating | |
|---|---|---|
| Bedroom vanity or reading nook | Pair with small side table for relaxed reading or personal grooming use | |
| Hotel lobby or lounge area | Deploy in clusters for modern commercial lounge waiting areas | |
| Office reception or breakout space | Install in informal meeting zones for casual guest and employee seating | |
| Balcony or sunroom casual seating | Position near windows for relaxed leisure seating with decorative appeal | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Seating furniture stability test standard for domestic and contract use | |
|---|---|---|
| EN 12520:2015 | Strength, durability and safety requirements for domestic seating | |
| EN 13501-1:2007+A1:2009 | Fire reaction classification for upholstered furniture components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Performance standard for lounge and public seating, applicable for commercial installations |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner plywood shell | |
|---|---|---|
| GB 20400-2006 | Limits of harmful substances in leather and fur, applicable to faux leather upholstery | |
| GB/T 19001-2016 | Quality management system guidance for furniture production compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner plywood shell; 2. GB 20400-2006: Limits of harmful substances in leather and fur, applicable to faux leather upholstery; 3. GB/T 19001-2016: Quality management system guidance for furniture production compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
