PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	838 × 775 × 838 mm
Seat height from floor	457 mm
Seat width	589 mm
Seat depth	610 mm
Backrest height above seat	381 mm
Four-star base leg span diameter	680 mm
Cushion thickness (seat)	127 mm
Outer shell wall thickness	12 mm
Clearance under seat to floor	152 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended static load capacity	136 kg
Net product weight	46 kg
Seat cushion foam density	35 kg/m³
Seat foam rebound rate	48%
Upholstery abrasion resistance	100000 double rubs
Swivel mechanism cycle life	30000 rotations
Seam stitch pitch	8 stitches per 25mm
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Outer structural shell	Curved bentwood plywood with dark walnut-toned finish
Seat and back cushion core	High-density polyurethane foam with fiber wrap
Upholstery cover	Light beige faux leather with channel-quilted stitching
Seat support system	Sinuous no-sag steel springs
Swivel base structure	Powder-coated matte black carbon steel four-star spider frame
Central swivel mechanism	Ball-bearing steel rotating plate
Base foot glides	Non-marking nylon floor protectors
Shell edge trim	Narrow black binding along upholstery and shell seam
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Swivel motion	360-degree free rotation on central ball bearing mechanism
Seating posture	Fixed 105-degree reclined back angle for relaxed lounging
Floor protection	Integrated nylon glides prevent floor scuffing on hard surfaces
Cushion construction	Segmented channel-quilted panels prevent fill shift during use
Structural support	Curved wrap-around shell provides lateral back and side support
Assembly requirement	Minimal base attachment to shell required for installation
Mobility feature	Stationary non-rocking, non-tilting fixed-position seating base
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential living room placement	Suitable as standalone accent seating adjacent to sofas or coffee tables
Office lounge and waiting area use	Appropriate for reception breakout zones and informal meeting spaces
Bedroom reading nook installation	Ideal for compact relaxation corners with plush, supportive cushioning
Hotel lobby and guest suite furnishing	Fits contemporary hospitality interiors with neutral tone and curved silhouette
Pairing recommendation	Coordinates with round marble or wood coffee tables and low-pile area rugs
Floor surface compatibility	Safe for hardwood, tile, and low-pile carpeted floors with integrated glides
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.4

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LGS-CS4-838

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LGS-CS4-838

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LGS-CS4-838Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Channel-Quilted Upholstered Swivel Lounge Chair with Curved Shell (model LGS-CS838unbranded) brings a streamlined contemporary silhouette to casual seating settings, defined by a smooth armless curved profile that balances soft upholstery with structured framing. Its wrap-around bentwood shell is finished in a dark walnut tone, trimmed with narrow black binding along the seam where the shell meets upholstered surfaces, creating a crisp visual contrast with the light beige faux leather cushions. The cushions feature defined channel-quilted stitching across the seat and back, supported by a matte black powder-coated four-star swivel base that sits flush with floor surfaces for a low-profile, uncluttered look.
Built for lasting regular use, the chair’s outer structure uses 12mm thick curved bentwood plywood, paired with a 14mm bentwood internal seat support board lined with sinuous no-sag steel springs. Seat and back cushion cores are constructed from high-density polyurethane foam wrapped in soft fiber, with a 127mm thick seat cushion that retains shape through repeated use; the segmented channel-quilted panel design prevents internal fill shift over time. The central swivel mechanism uses a ball-bearing steel rotating plate, attached to a carbon steel four-star spider frame fitted with non-marking nylon glides. The upholstery resists surface wear from regular contact, while the swivel mechanism delivers smooth 360-degree free rotation without rocking or tilting, holding a fixed 105-degree reclined back angle to support relaxed, upright-lounging postures with built-in lateral back and side support from the curved shell.
This chair fits seamlessly across both residential and commercial spaces. In homes, it works as standalone accent seating next to sofas or coffee tables in living rooms, or as a dedicated seat for compact bedroom reading nooks. For commercial settings, it suits office reception breakout zones, informal meeting spaces, hotel lobbies, and guest suites, pairing naturally with round marble or wood coffee tables and low-pile area rugs. Its integrated glides make it safe for use on hardwood, tile, and low-pile carpeted floors.
Procurement teams should note minimal assembly is required, with only base attachment to the shell needed for installation, taking roughly 40 minutes per unit. Each set ships across two cartons, with freight planning aligned to standard 20GP container loading capacities for bulk orders. The chair holds a recommended static load capacity suitable for general adult use, with a fixed stationary base that eliminates unintended movement for stable seating in high-traffic shared spaces.

Channel-Quilted Upholstered Swivel Lounge Chair with Curved Shell Specifications
