Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 750 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single chair static load capacity | 150 kg | |
|---|---|---|
| Set total net weight | 82 kg | |
| Seating capacity | 4 persons | |
| Upholstery fabric abrasion resistance | 30000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles | |
| Gas-lift Cycling Reference | Acceptance target 100000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair upholstery | 0.9mm thick matte faux leather | |
|---|---|---|
| Chair cushion fill | 35kg/m³ high-resilience polyurethane foam | |
| Chair structural frame | 1.5mm thick matte black powder-coated carbon steel tubing | |
| Coffee table top | 12mm thick matte white sintered stone | |
| Table support base | 1.2mm thick matte black powder-coated tapered steel cone | |
| Table accent trim | Polished gold PVD-coated stainless steel collar and base ring | |
| Included throw pillows | Faux leather cover with polyfiber fill | |
| Chair leg foot pads | Non-slip PVC floor protection pads | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Chair back support | Curved low-profile wraparound back with integrated armrests | |
|---|---|---|
| Chair seating configuration | Freestanding non-stackable static seating units | |
| Table base design | Weighted conical single pedestal with anti-tip gold base plate | |
| Seating comfort feature | Double-layer thickened seat cushion for pressure distribution | |
| Seating arrangement | Circular four-person face-to-face conversation layout | |
| Floor protection | Non-marking foot caps on all chair legs prevent hard floor scratches | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Hotel lobby lounge areas | Small-scale casual seating for guest waiting and short conversations | |
|---|---|---|
| Office reception zones | 4-person seating for visitor greeting and informal meetings | |
| Residential living room nooks | Compact conversation set for small apartment leisure spaces | |
| Upscale cafe casual seating | Low-height seating for light refreshments and social visits | |
| Beauty salon waiting areas | Comfortable upholstered seating for pre-service guest waiting | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
