Automatic mm / inch conversion · Core engineering specifications
| Overall armchair dimensions (per chair) | 840 x 840 x 870 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat width | 620 mm | |
| Seat depth | 580 mm | |
| Backrest height above seat | 420 mm | |
| Armrest height above seat | 200 mm | |
| Overall side table dimensions | 500 x 500 x 550 mm | |
| Side table glass top diameter | 500 mm | |
| Side table under-table clearance | 480 mm | |
| Side table lower cross brace height | 250 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Armchair net weight | 22 kg | |
|---|---|---|
| Armchair static load capacity | 227 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam thickness | 120 mm | |
| Back foam thickness | 80 mm | |
| Recommended seat count | 1 person per chair | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and inner back upholstery | Orange matte faux leather, 1.2mm thickness | |
|---|---|---|
| Outer back and arm wrap upholstery | Off-white quilted woven fabric, diamond stitching | |
| Seat cushion padding | High-density polyurethane foam, 45kg/m³ density | |
| Inner chair frame | Solid kiln-dried hardwood, 25mm thickness | |
| Swivel base mechanism | Powder-coated black steel, 3mm plate thickness | |
| Side table top | Clear tempered glass, 8mm thickness, solid walnut-look engineered wood rim | |
| Side table legs and cross brace | Black powder-coated 16mm diameter steel tube | |
| Side table foot pads | Non-slip PVC pads, 5mm thickness | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seat rotation mechanism | 360-degree smooth ball-bearing swivel, no tilt lock | |
|---|---|---|
| Armrest integration | Fully integrated wrap-around arm and back structure, no separate adjustable parts | |
| Base floor protection | Concealed swivel base with smooth bottom glides, no visible casters | |
| Side table assembly | Knockdown leg attachment with included hex key, no permanent adhesives | |
| Side table surface function | Smooth tempered glass top supports drinkware, small plants and personal items | |
| Upholstery maintenance | Faux leather surfaces wipe clean with damp cloth; fabric outer panel requires gentle vacuuming | |
| Set configuration | Two identical armchairs paired with one central side table for two-person reception layouts | |
| Swivel base diameter | 600 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception areas | Two-person seating for visitor waiting zones, provides compact professional seating | |
|---|---|---|
| Corporate lounge breakout spaces | Supports informal employee relaxation and small impromptu discussions | |
| Hotel lobby guest seating | Two-tone design fits modern boutique and business hotel lobby layouts | |
| Residential living room accent seating | Pairs as accent chairs for small apartment open-concept living areas | |
| Retail showroom consultation zones | Provides comfortable seating for client consultations and product discussions | |
| Healthcare waiting rooms | Easy-clean faux leather surfaces support high-traffic public space maintenance | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture – Strength, durability and safety for domestic seating | |
|---|---|---|
| EN 1022:2018 | Furniture – Seating – Determination of stability | |
| EN 15372:2016 | Furniture – Durability requirements for non-domestic tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Lounge and public seating safety and performance standard | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Desk and table products performance and safety standard | |
| ANSI/BIFMA X5.1-2017 | General office chairs, applicable for swivel mechanism durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the chair frame | |
|---|---|---|
| GB 28007-2011 | Safety requirements for children's furniture, applicable if used in public family areas | |
| GB/T 19001-2016 | Quality management system guidance for consistent production quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the chair frame; 2. GB 28007-2011: Safety requirements for children's furniture, applicable if used in public family areas; 3. GB/T 19001-2016: Quality management system guidance for consistent production quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
