Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint diameter | 2200 mm | |
|---|---|---|
| Round table top diameter | 800 mm | |
| Table total height | 600 mm | |
| Table base foot plate diameter | 450 mm | |
| Chair overall dimensions (W x D x H) | 750 x 700 x 800 mm | |
| Chair seat height from floor | 420 mm | |
| Chair seat depth | 580 mm | |
| Chair backrest height above seat | 380 mm | |
| Table mid-shelf diameter | 250 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 78 kg | |
|---|---|---|
| Per-chair static load capacity | 150 kg | |
| Seating capacity | 4 persons | |
| Chair foam density | 28D | |
| Upholstery abrasion resistance | 30000 rub cycles | |
| Swivel mechanism cycle rating | 20000 rotations | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table top | 12mm thick polished white sintered stone slab | |
|---|---|---|
| Table pedestal and base | 1.5mm thick carbon steel with brushed gold finish | |
| Chair internal frame | 20mm thick kiln-dried solid hardwood | |
| Chair upholstery | 0.8mm thick matte orange velvet fabric | |
| Chair seat cushion fill | 120mm thick high resilience polyurethane foam | |
| Chair backrest fill | 80mm thick high density foam with vertical channel quilting | |
| Chair swivel mechanism | Powder-coated steel rotating plate with ball bearings | |
| Seam stitching | Polyester thread with 8mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Chair rotation | 360° smooth swivel without tilt lock | |
|---|---|---|
| Back support | Curved wrap-around channel-tufted back with integrated low armrests | |
| Table surface | Stain-resistant non-porous stone top for drink and decor placement | |
| Assembly requirement | Knockdown assembly for table pedestal to top, minimal tool use | |
| Floor protection | Felt pads fitted under chair bases and table foot plate | |
| Seat design | Wide rounded seat without protruding arms for flexible sitting positions | |
| Chair swivel base diameter | 620 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Circular seating cluster for casual conversation adjacent to media areas | |
|---|---|---|
| Office reception area | Compact waiting seating for 4 guests in boutique office or lounge spaces | |
| VIP negotiation space | Comfortable casual meeting setup for small client discussions in sales centers | |
| Hotel lounge area | Seating for guest relaxation in boutique hotel lobbies or club common areas | |
| Showroom display | Glam-style display set for furniture retail or residential model home staging | |
| Apartment lounge nook | Space-efficient seating for small urban living spaces requiring flexible arrangement | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety for domestic seating | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety for non-domestic tables | |
| EN 1022:2018 | Furniture - Seating stability test methods for swivel chairs | |
| EN 13722:2004 | Furniture - Test methods for table surface resistance to wear |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for lounge seating performance and safety, commercial use reference | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for occasional table performance and durability, reference for table | |
| ANSI/BIFMA X5.1-2017 | Reference for swivel mechanism durability and static load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to chair frame construction | |
|---|---|---|
| GB/T 24821-2009 | Performance requirements for metal furniture bases, applicable to table pedestal | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to chair frame construction; 2. GB/T 24821-2009: Performance requirements for metal furniture bases, applicable to table pedestal; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
