Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 760 x 790 x 830 mm | |
|---|---|---|
| Seat width | 640 mm | |
| Seat depth | 510 mm | |
| Seat height from floor | 480 mm | |
| Backrest total height | 530 mm | |
| Armrest height from seat | 200 mm | |
| Leg height | 230 mm | |
| Gold ferrule length | 50 mm | |
| Seat cushion thickness | 120 mm | |
| Central back cutout width | 480 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 160 kg | |
|---|---|---|
| Net product weight | 15 kg | |
| Seating capacity | 1 person | |
| Cushion foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Leg static load per leg | 45 kg | |
| Upholstery abrasion resistance | 30000 rubs | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest upholstery | Matte grey woven polyester fabric | |
|---|---|---|
| Seat upholstery | Mustard yellow woven polyester fabric | |
| Cushion core | High-density polyurethane foam | |
| Inner frame | Solid kiln-dried pine wood | |
| Legs | Solid beech wood with matte black finish | |
| Leg ferrules | Polished gold-plated metal caps | |
| Seat base support | 8mm thick plywood panel | |
| Seam stitching | Polyester thread with 8mm stitch pitch | |
| Foot pads | Non-slip plastic floor protectors | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Integrated armrest support | Curved back frame extends down to form wrap-around armrests | |
|---|---|---|
| Open back cutout | Central arched cutout reduces visual weight and improves airflow | |
| Splayed leg stability | Four legs angle outward to increase base footprint and tip resistance | |
| Knockdown assembly | Legs attach to seat frame with included hardware for flat-pack shipping | |
| Fixed seating position | Static upright lounge posture with no recline or swivel mechanism | |
| Spot clean maintenance | Upholstery can be cleaned with damp soft cloth for regular care | |
| Leveling adjustment | Gold ferrules include small adjustable feet to balance on uneven floors | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Living room accent seating | Place next to sofa or coffee table as decorative additional guest seating | |
|---|---|---|
| Bedroom corner seating | Position in bedroom nook or dressing area for relaxed casual seating | |
| Home office reception seating | Use in small home office or studio waiting area for short-term visitor seating | |
| Entryway foyer seating | Place near entry for putting on shoes or decorative welcome seating | |
| Hotel boutique lounge seating | Deploy in hotel lobbies or boutique guest areas for stylish guest seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture flammability resistance to cigarette ignition source |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame and leg construction | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, required for formaldehyde emissions | |
| GB/T 19823-2005 | Performance requirements for upholstered furniture seating, applicable for cushion durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame and leg construction; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, required for formaldehyde emissions; 3. GB/T 19823-2005: Performance requirements for upholstered furniture seating, applicable for cushion durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
