Automatic mm / inch conversion · Core engineering specifications
| Overall chair dimensions | 690 x 750 x 840 mm | |
|---|---|---|
| Matching ottoman dimensions | 690 x 470 x 470 mm | |
| Seat height from floor | 470 mm | |
| Seat depth for upright lounge posture | 620 mm | |
| Backrest height above seat | 370 mm | |
| Ottoman internal arch cutout height | 220 mm | |
| Upholstered wall thickness at curved edges | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load per seat | 159 kg | |
|---|---|---|
| Recommended static load per ottoman | 100 kg | |
| Net weight per chair unit | 28 kg | |
| Foam core density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Product warranty period | 3 years | |
| Seat width for single occupant | 690 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery fabric | 300g/m² white polyester-linen woven blend | |
|---|---|---|
| Seat and back core filling | High-density polyurethane foam with wrapped fiber layer | |
| Internal support frame | 30mm thick kiln-dried pine solid wood frame | |
| Modular connecting hardware | Zinc-plated steel hook and D-ring clips | |
| Hidden base structure | Non-slip polyester felt floor pads under each module | |
| Fabric seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Backrest internal support | Curved plywood liner within foam core | |
| Fabric finish treatment | Stain-repellent surface coating | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Modular interlock system | Clip-on hook fasteners connect chair and ottoman to prevent sliding | |
|---|---|---|
| Freestanding configuration | Units may be separated for use as standalone chair and separate footrest | |
| Floor-resting support | Integral curved base eliminates separate legs for low-profile silhouette | |
| Back support posture | Contoured 105° angled backrest for relaxed semi-reclined seating | |
| Ottoman secondary use | Cylindrical ottoman supports elevated leg rest or extra casual seating | |
| Non-marking placement | Felt base glides protect wood, tile, and polished concrete floors | |
| Removable cover access | Hidden zippers along upholstery seams allow cover removal for cleaning | |
| Interlocking hook engagement depth | 100 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions per unit | 1000 x 780 x 570 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room accent seating | Low-profile sculptural form fits modern minimalist and cream-style interiors | |
|---|---|---|
| Bedroom relaxation nook | Compact footprint works for bedroom corner or reading space | |
| Office lounge and waiting areas | Soft casual seating supports informal break-out and guest waiting zones | |
| Boutique retail and exhibition spaces | Sculptural curved form adds visual interest to display and public waiting areas | |
| Balcony and sunroom casual seating | Light fabric and low profile fit relaxed enclosed sunroom spaces | |
| Modular flexible layout configurations | Multiple sets can be clustered to create larger custom lounge arrangements | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance test for smouldering cigarette |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Performance and safety standard applicable for lounge seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to wooden frame upholstered furniture | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limits applicable for indoor residential furniture | |
| GB/T 1952.1-2012 | Mechanical performance test requirements applicable to upholstered seating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to wooden frame upholstered furniture; 2. GB 18584-2001: Formaldehyde emission limits applicable for indoor residential furniture; 3. GB/T 1952.1-2012: Mechanical performance test requirements applicable to upholstered seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
