Automatic mm / inch conversion · Core engineering specifications
| Table overall dimensions | 700 mm diameter, 750 mm height | |
|---|---|---|
| Table under-table knee clearance height | 680 mm | |
| Table base span width | 660 mm | |
| Integrated power outlet spacing | 180 mm | |
| Chair overall dimensions per unit | 660 mm width, 620 mm depth, 760 mm height | |
| Chair seat height | 460 mm | |
| Chair seat depth | 500 mm | |
| Chair backrest height | 340 mm | |
| Chair armrest height above seat | 180 mm | |
| Chair floor glide diameter | 20 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Table total static load capacity | 50 kg | |
|---|---|---|
| Per-chair maximum user weight capacity | 130 kg | |
| Per-chair seat cushion foam density | 45 kg/m³ | |
| Per-chair back cushion foam thickness | 40 mm | |
| Set total net weight | 79 kg | |
| Recommended seating capacity | 3 people | |
| Upholstery seam stitch pitch | 8 stitches per 30 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface | White high-pressure laminate, 25 mm thick | |
|---|---|---|
| Table edge banding | 2 mm thick PVC edge, color-matched to white tabletop | |
| Table support columns | Powder-coated steel, 50 mm diameter dual tubes, 1.2 mm wall thickness | |
| Table tripod base frame | Powder-coated flat steel, 3 mm thick three-prong star structure | |
| Integrated power module housing | Flame-retardant ABS plastic, flush-mounted to tabletop | |
| Chair outer upholstery | 100% polyester woven fabric, 0.8 mm thick, 30000-cycle abrasion rating | |
| Chair inner support frame | 15 mm thick plywood carcass with internal bracing | |
| Chair seat cushion core | High-resilience polyurethane foam, 50 mm thickness, 42% rebound rate | |
| Chair block base plinth | Upholstery-covered plywood frame with floor protection glides | |
| Chair floor glides | Nylon base with felt contact pad | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop power access | Two flush-mounted AC outlets positioned at table center | |
|---|---|---|
| Table cable management | Internal cable routing through dual steel support columns | |
| Table base stability | Three-prong star base with floor contact at three end points | |
| Chair seating support | Continuous curved wrap-around back and integrated armrests | |
| Chair leg clearance cutout | Recessed front cutout at lower seat plinth | |
| Chair floor protection | Small felt-padded glides at all base corners | |
| Set arrangement flexibility | Lightweight individual chairs can be rotated 360 degrees around table | |
| Chair stackability | Non-stackable solid block base design | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office informal meeting spaces | Suitable for 3-person quick discussions in breakout zones | |
|---|---|---|
| Cafe and bistro waiting areas | Works for customer seating with device charging capability | |
| Lobby reception waiting zones | Provides comfortable stationary seating for short-term visitor use | |
| Co-working space lounge areas | Supports impromptu work sessions with accessible power outlets | |
| Retail customer consultation zones | Creates approachable seating for client conversations | |
| Public lounge break areas | Stain-resistant laminate and woven fabric simplify routine cleaning | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Commercial furniture strength durability for tables | EN 15372:2008+A1:2016 | |
|---|---|---|
| Upholstered seating fire resistance for non-domestic use | EN 1021:2014 | |
| Office visitor seating strength stability | EN 16139:2013 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| Table commercial furniture mechanical safety | GB/T 3324 | |
|---|---|---|
| Upholstered furniture formaldehyde emission | GB 18584 |
This product must meet the following technical requirements: 1. Table commercial furniture mechanical safety: GB/T 3324; 2. Upholstered furniture formaldehyde emission: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
