Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 800 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Floor base plate diameter | 450 mm | |
| Pedestal top mounting plate diameter | 380 mm | |
| Under-table knee clearance height | 690 mm | |
| Clearance radius around pedestal | 190 mm | |
| Tabletop edge thickness | 25 mm | |
| Base wall thickness | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load | 100 kg | |
|---|---|---|
| Unit net weight | 28 kg | |
| Seating capacity | 2 people | |
| Tip resistance load angle | 15 degrees | |
| Surface scratch resistance | 2000 abrasion cycles | |
| Adjustable glide adjustment range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 25mm thick E0-grade engineered wood | |
|---|---|---|
| Tabletop surface finish | Matte black scratch-resistant laminate coating | |
| Central pedestal support | Powder-coated carbon steel with conical taper | |
| Floor base plate | Flat circular steel plate with powder-coated finish | |
| Mounting hardware | Zinc-plated steel bolts with pre-drilled attachment points | |
| Floor protectors | Non-slip nylon adjustable glides | |
| Finish coating thickness | 80 um | |
| Substrate moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Support structure | Single central conical pedestal | |
|---|---|---|
| Assembly requirement | Partial knock-down assembly | |
| Floor leveling | 4 adjustable nylon glides | |
| Surface usability | Non-porous matte tabletop | |
| Storage/extension | Fixed non-extendable, no built-in storage | |
| Mobility | Fixed stationary placement | |
| Cable management | No integrated cable routing | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Office reception lounge | Suitable for casual visitor waiting areas, paired with matching upholstered armchairs | |
|---|---|---|
| Hotel café and bistro areas | Compact footprint fits small seating zones for two-guest beverage service | |
| Residential small dining nooks | Fits studio apartments or kitchen corners for compact 2-person dining | |
| Co-working breakout spaces | Ideal for informal meetings, coffee breaks, and short collaborative discussions | |
| High-end retail VIP areas | Provides refined minimalist seating for private client consultation spaces |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic dining tables, applicable to structural validation | |
|---|---|---|
| EN 15372:2008 | Furniture safety, strength and durability for non-domestic tables, applicable to commercial café use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk and table products standard, applicable to commercial grade performance verification |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate performance | |
|---|---|---|
| GB/T 4893.8-2013 | Furniture surface abrasion resistance test method, applicable to finish durability verification | |
| GB/T 10357.1-2013 | Furniture mechanical test for tables, applicable to static load and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate performance; 2. GB/T 4893.8-2013: Furniture surface abrasion resistance test method, applicable to finish durability verification; 3. GB/T 10357.1-2013: Furniture mechanical test for tables, applicable to static load and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
