Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 750 x 730 x 750 mm | |
|---|---|---|
| Seat height | 480 mm | |
| Seat width | 597 mm | |
| Seat depth | 597 mm | |
| Backrest height | 420 mm | |
| Armrest height | 220 mm | |
| Base glide height | 15 mm | |
| Throw pillow dimensions | 450 x 450 mm | |
| Seat cushion thickness | 165 mm | |
| Armrest width | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static weight capacity | 160 kg | |
|---|---|---|
| Net weight per unit | 20 kg | |
| Seat cushion foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Floor glide static load rating | 50 kg per glide | |
| Seat support spring count | 4 sinuous springs | |
| Available color options | 8 | |
| Limited commercial warranty | 1 year | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | 1.0mm thick PU faux leather | |
|---|---|---|
| Internal frame | 18mm thick plywood and solid engineered wood | |
| Seat cushion fill | High-density polyurethane foam | |
| Backrest fill | 30kg/m³ soft polyurethane foam | |
| Seat support system | Heavy-duty polypropylene webbing and sinuous springs | |
| Floor glides | Black hard nylon glides | |
| Stitching construction | High-tensile polyester thread, 8mm seam pitch | |
| Throw pillow fill | Hollow conjugate polyester fiber | |
| Base structure | Upholstered engineered wood block base | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Single-person fixed-height lounge seat | |
|---|---|---|
| Back support | Continuous curved barrel back encloses seated user | |
| Armrest design | Integrated padded armrests run full seat depth | |
| Lumbar support | Included matching upholstered throw pillow | |
| Mobility | Fixed non-swivel, non-reclining structure | |
| Floor protection | Four low-profile nylon glides at base corners | |
| Cleaning method | Wipe-clean faux leather surface | |
| Assembly requirement | Minimal tool-free glide attachment | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception areas | Suitable for waiting zones, provides comfortable guest seating with professional aesthetic | |
|---|---|---|
| Lounge and break rooms | Fits casual relaxation spaces paired with side tables for beverages and personal items | |
| Small apartment living rooms | Compact footprint fits studio and small-space residential seating arrangements | |
| Hotel lobbies and guest areas | Durable upholstery withstands high-traffic public area use | |
| Bedroom accent seating | Functions as a dressing or reading chair placed near windows or wardrobes | |
| Cafe and co-working spaces | Works for informal meeting nooks and individual casual work seating | |
| Healthcare waiting rooms | Easy-clean faux leather surface supports regular sanitization between users | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture seating, test method for determination of stability, applicable to tip-over resistance testing | |
|---|---|---|
| EN 16139:2013 | Non-domestic seating strength, durability and safety requirements, applicable for commercial reception use | |
| EN 1335-2:2018 | Reference for static load and durability requirements for seating used in public office spaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.41-2020 | Lounge and public seating standard, applicable for static load and structural durability validation | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | Reference for strength and stability test methods for general purpose office seating | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, reference for material emissions and recyclability criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and base structural stability | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, covers formaldehyde emission limits for frame materials | |
| GB/T 19001-2016 | Quality management system reference for consistent production of upholstered seating components | |
| GB/T 35607-2017 | Green product assessment specification for furniture, applicable for low-VOC upholstery and frame material selection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and base structural stability; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, covers formaldehyde emission limits for frame materials; 3. GB/T 19001-2016: Quality management system reference for consistent production of upholstered seating components; 4. GB/T 35607-2017: Green product assessment specification for furniture, applicable for low-VOC upholstery and frame material selection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
