Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 940 x 920 x 800 mm | |
|---|---|---|
| Seat height from floor | 425 mm | |
| Seat width between armrests | 560 mm | |
| Seat depth (front to back) | 580 mm | |
| Backrest total height above seat | 375 mm | |
| Armrest height above seat | 180 mm | |
| Under-seat clearance height | 120 mm | |
| Sled base footprint length | 680 mm | |
| Sled base footprint width | 620 mm | |
| Armrest top height from floor | 605 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 35 kg | |
| Seat foam core density | 40 kg/m³ | |
| Seat foam total thickness | 120 mm | |
| Backrest foam thickness | 80 mm | |
| Seam stitch pitch | 8 stitches per inch | |
| Upholstery fabric abrasion resistance | 50000 Martindale cycles | |
| Surface warranty period | 2 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and inner back upholstery | Blush polyester velvet fabric | |
|---|---|---|
| Outer side shell upholstery | Peach woven grid-texture fabric | |
| Internal support frame | 18mm thick engineered plywood | |
| Seat cushion padding | High-density polyurethane foam with 20mm polyester fiber wrap | |
| Back and arm padding | 35kg/m³ density polyurethane foam | |
| Base frame construction | 20x40mm rectangular steel tube | |
| Base finish | Matte black powder coating | |
| Floor contact pads | 10mm thick non-slip felt pads | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Single-person fixed lounge seat with integrated curved armrests | |
|---|---|---|
| Backrest orientation | Fixed 105-degree angled back for relaxed lounge posture | |
| Base mobility | Fixed non-swivel, non-tilting sled base | |
| Under-seat design | Open central void between tapered upholstered side supports | |
| Floor protection | Integrated non-marking felt glides on all base contact points | |
| Assembly requirement | Minimal tool-free attachment of base to upholstered shell | |
| Upholstery application | Tailored upholstery with clean finished edges on all shell seams | |
| Weight distribution | Dual tapered side supports transfer load evenly across the sled base | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room accent seating | Placed as a standalone statement chair beside sofas or reading nooks | |
|---|---|---|
| Lobby and reception lounge areas | Used for visitor seating in hotel, office or gallery reception zones | |
| Bedroom dressing area seating | Positioned near vanities or walk-in closets for relaxed seating | |
| Breakout and collaborative office zones | Deployed in informal office breakout areas for casual meetings | |
| Waiting room seating | Installed in clinic or salon waiting areas for guest comfort | |
| High-end retail display vignettes | Used as display seating in furniture showrooms or retail boutiques | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture seating stability test method applicable for fixed lounge chairs | |
|---|---|---|
| EN 12520:2015 | Furniture seating strength/durability for domestic use | |
| EN 16139:2013 | Contract non-domestic seating strength requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating standard for public/office use | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office chairs strength/durability reference |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture applicable to internal frame | |
|---|---|---|
| GB 20400-2006 | Applicable standards and test results require confirmation | |
| GB/T 19001-2016 | Quality management system guideline for furniture manufacturing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture applicable to internal frame; 2. GB 20400-2006: Applicable standards and test results require confirmation; 3. GB/T 19001-2016: Quality management system guideline for furniture manufacturing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
