Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 790 x 790 x 1080 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat width | 680 mm | |
| Seat depth | 560 mm | |
| Backrest height | 760 mm | |
| Armrest height from floor | 620 mm | |
| Seat cushion thickness | 120 mm | |
| Four-star base radius | 340 mm | |
| Headrest height | 280 mm | |
| Armrest width | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight | 31 kg | |
|---|---|---|
| Recommended static load capacity | 159 kg | |
| Swivel rotation range | 360 degrees | |
| Backrest recline angle | 20 degrees | |
| Seat foam density | 40 kg/m³ | |
| Foam rebound rate | 55 percent | |
| Base static load rating | 200 kg | |
| Floor protection rating | 10000 rotations | |
| Warranty period | 1825 days | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner seat/back frame | 25mm thick solid hardwood + plywood frame | |
|---|---|---|
| Upholstery fabric | 380gsm two-tone woven polyester chenille | |
| Seat cushion padding | 120mm thick high-density polyurethane foam + 20mm dacron wrap | |
| Backrest padding | 80mm thick medium-density polyurethane foam with fiber topper | |
| Four-star base | Dark walnut-stained solid wood veneer over steel core | |
| Swivel mechanism | 3mm thick cold-rolled steel 360° swivel plate | |
| Floor glides | 8mm thick felt pads under each base prong | |
| Outer shell upholstery | Dark charcoal woven fabric on seat and headrest outer sides | |
| Inner contact upholstery | Light off-white woven fabric on seat, arm tops, back cushions | |
| Suspension system | 50mm wide elastic webbing under seat cushion | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Swivel operation | Smooth 360° non-return rotation with no auto-reverse | |
|---|---|---|
| Seating posture | Fixed 20° relaxed back recline with integrated head support | |
| Arm support | Curved enclosed integrated armrests wrap around seat perimeter | |
| Head support | Raised fixed integrated headrest aligned with neck height | |
| Floor compatibility | Felt glides suitable for hardwood, tile, and low-pile carpet floors | |
| Assembly requirement | Base attaches to seat shell with included hardware in 50 minutes | |
| Upholstery care | Spot-clean only with mild fabric detergent | |
| Color option count | 4 standard two-tone fabric combinations | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Carton dimensions | 900 x 850 x 800 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Primary placement as standalone reading or relaxation seating | |
|---|---|---|
| Office lounge area | Suitable for casual meeting and break spaces in workplaces | |
| Hotel guest room seating | Pairs with side tables for premium hospitality accommodation use | |
| Reception waiting area | Provides comfortable seating for visitors in modern lobbies | |
| Reading nook placement | Ideal next to windows or bookshelves for extended reading sessions | |
| Bedroom accent seating | Functions as corner seating for master bedrooms or dressing areas | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Non-domestic seating strength/durability standard for lounge furniture | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture cigarette ignition resistance requirement | |
| EN 1021-2:2014 | Upholstered furniture match flame ignition resistance requirement | |
| EN 12520:2015 | Domestic furniture seating strength, durability and safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating durability and safety standard for public/residential use | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office seating test reference for swivel mechanism durability | |
| BIFMA e3-2019 | Furniture sustainability standard for material and emission compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and base construction | |
|---|---|---|
| GB 20400-2006 | Leather/fur safety limits, applicable for optional leather upholstery variants | |
| GB/T 19001-2016 | Quality management system guidance for production consistency | |
| GB 18584-2001 | Indoor decoration material limits for formaldehyde content in wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and base construction; 2. GB 20400-2006: Leather/fur safety limits, applicable for optional leather upholstery variants; 3. GB/T 19001-2016: Quality management system guidance for production consistency; 4. GB 18584-2001: Indoor decoration material limits for formaldehyde content in wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
