Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 850 x 880 x 790 mm | |
|---|---|---|
| Seat width | 560 mm | |
| Seat depth | 560 mm | |
| Seat height from floor | 420 mm | |
| Seat cushion thickness | 130 mm | |
| Backrest height from seat | 370 mm | |
| Armrest height from seat | 180 mm | |
| Leg spread (front width) | 720 mm | |
| Leg height | 200 mm | |
| Outer side panel thickness | 40 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight | 36 kg | |
|---|---|---|
| Recommended static load capacity | 200 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Floor glide load rating per leg | 60 kg | |
| Recommended warranty period | 60 months | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main seat/back upholstery | Top-grain cognac brown leather, 1.4mm thickness | |
|---|---|---|
| Outer side panel upholstery | Contrast smooth taupe leather, 1.2mm thickness | |
| Internal frame | 18mm thick plywood + engineered wood, reinforced corner blocking | |
| Seat cushion fill | High-density polyurethane foam, dacron wrap | |
| Backrest fill | 35kg/m³ density polyurethane foam, soft fibre topper | |
| Support legs | 2.5mm thick black powder-coated steel, splayed angled geometry | |
| Seam trim | Matching leather piping, 8mm stitch pitch | |
| Floor glides | Non-marking nylon glides, fixed to leg bases | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating posture | Fixed relaxed lounge angle, 105° backrest recline from seat | |
|---|---|---|
| Arm support | Asymmetrical continuous wrap arm integrated with backrest | |
| Base stability | Four outward-splayed steel legs with central cross support | |
| Assembly requirement | Knock-down leg attachment with included hardware | |
| Surface protection | Non-marking glides prevent floor scuffing on hard surfaces | |
| Upholstery maintenance | Wipe-clean leather surface suitable for regular commercial cleaning | |
| Stacking compatibility | Non-stackable fixed upholstered form | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Accent seating for conversation areas or reading nooks, low lounge profile | |
|---|---|---|
| Commercial lobby | Guest seating in hotel reception or office waiting areas, durable leather finish | |
| Executive office lounge | Casual meeting seating in private office breakout zones | |
| Lounge bar and cafe | Premium guest seating for high-end hospitality venues | |
| Pairing configuration | Two chairs placed with a small coffee table for two-person seating arrangements | |
| Color matching | Pairs with dark wood, black metal, or neutral stone furniture finishes | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture strength, durability and safety for domestic seating | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability test method |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating durability and safety standard for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General purpose office chairs static load test reference for fixed seating |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame components | |
|---|---|---|
| GB 20400-2006 | Leather fur limits of harmful substances, applicable to leather upholstery | |
| GB/T 16799-2008 | Furniture use leather technical specifications, applicable to upholstery materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame components; 2. GB 20400-2006: Leather fur limits of harmful substances, applicable to leather upholstery; 3. GB/T 16799-2008: Furniture use leather technical specifications, applicable to upholstery materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
