Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 700 × 650 × 780 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single chair static load capacity | 150 kg | |
|---|---|---|
| Single chair net weight | 16 kg | |
| Seat cushion foam density | 35 kg/m³ | |
| Back cushion fill weight | 0.8 kg | |
| Recommended maximum seating duration | 4 hours | |
| Chair leg floor load spread | 20 mm diameter foot cap | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair seat and back upholstery | 280g/m² linen-look polyester fabric | |
|---|---|---|
| Chair seat cushion core | 80mm thick high-resilience polyurethane foam | |
| Chair backrest inner frame | 15mm thick multilayer plywood | |
| Teal chair frame and legs | 1.2mm thick matte gold plated carbon steel | |
| Blush chair frame and legs | 1.2mm thick matte black powder coated carbon steel | |
| Coffee table tabletop | 20mm polished engineered sintered stone | |
| Coffee table middle column | 2mm thick matte black powder coated steel | |
| Coffee table lower base | 20mm thick white marble-look engineered stone | |
| Coffee table decorative trim | 0.8mm polished gold plated steel ring | |
| Floor contact pads | 5mm thick non-slip rubber | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Armless chair design | Curved enveloping backrest wraps 120 degrees around seat | |
|---|---|---|
| Matching throw cushion | Removable square cushion placed against backrest | |
| Four-leg splayed base | 15-degree outward angled legs for 380mm support footprint | |
| Coffee table weighted base | Wide conical lower base lowers center of gravity | |
| Smooth rounded table edge | 2mm radius polished edge on tabletop | |
| Non-marking floor glides | Fixed rubber caps on all leg and base contact points | |
| Mixed leg finish configuration | Two chairs with gold legs, two chairs with black legs | |
| Stationary non-swivel seating | Fixed connection between seat frame and legs | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception areas | 4-seat configuration for small guest waiting spaces adjacent to entry points | |
|---|---|---|
| Cafe and tea lounge seating | Suitable for casual beverage service with central table for drink placement | |
| Breakout meeting zones | Small informal discussion areas in open plan workplaces | |
| Boutique retail waiting areas | Upscale two-tone design fits beauty salons, fashion boutiques and showroom spaces | |
| Residential living room accent seating | Small conversation set for apartment living rooms or studio spaces | |
| Hotel corridor and lift lobby seating | Stable non-tip design suitable for high foot traffic public hospitality areas | |
| Co-working space casual zones | Flexible seating for informal collaboration and individual short work breaks | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Seating strength and stability recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface durability recommendation | EN 12720:2009+A1:2013 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Lounge seating structural recommendation | ANSI/BIFMA X2021 | |
|---|---|---|
| Occasional table stability recommendation | ANSI/BIFMA X2021 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 27030 | |
|---|---|---|
| Fabric flame retardancy recommendation | GB 20286 | |
| Formaldehyde emission recommendation | GB 18584 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 27030; 2. Fabric flame retardancy recommendation: GB 20286; 3. Formaldehyde emission recommendation: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
