Automatic mm / inch conversion · Core engineering specifications
| Set overall footprint | 2400 x 2400 x 800 mm | |
|---|---|---|
| Round coffee table dimensions | 800 mm diameter x 480 mm height | |
| Single lounge chair overall dimensions | 740 mm width x 750 mm depth x 800 mm height | |
| Chair seat height | 450 mm | |
| Chair seat dimensions | 550 mm width x 500 mm depth | |
| Chair back height above seat | 350 mm | |
| Chair arm height above seat | 200 mm | |
| Table base diameter at floor | 400 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Per-chair static load capacity | 150 kg | |
|---|---|---|
| Foam density (seat and back) | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Seat foam thickness | 80 mm | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Set total net weight | 110 kg | |
| Seating capacity | 4 people | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Chair upholstery | Wear-resistant polyester fabric, two-tone grey and red finish | |
|---|---|---|
| Chair internal frame | 20 mm tubular powder-coated dark steel frame | |
| Chair padding | High-density polyurethane rebound foam | |
| Lumbar cushion pad | Matching fabric-wrapped soft foam insert | |
| Table tabletop | 8 mm thick black matte laminated MDF | |
| Table pedestal base | 1.5 mm thick conical black powder-coated steel | |
| Frame accent hardware | Brushed brass/gold finish steel trim | |
| Chair floor glides | Non-marking plastic foot caps | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed circular 4-person layout | |
|---|---|---|
| Table access | Central single pedestal base, no perimeter legs | |
| Chair mobility | Stationary fixed-position seating, no casters or swivel mechanism | |
| Back support design | Curved wrap-around enclosed back with integrated lumbar pad | |
| Armrest structure | Continuous tubular metal frame forming integrated armrests and front legs | |
| Cleaning access | Smooth upholstered surfaces with no recessed tufting | |
| Assembly requirement | Knock-down construction, table base and chair frames attach with included hardware | |
| Floor protection | Non-marking glides on all chair legs and table base | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception and lobby areas | Provides 4-person casual seating for visitor waiting and informal check-in conversations | |
|---|---|---|
| Corporate break and lounge zones | Supports short rest periods and informal small group discussions for staff | |
| Hotel public waiting areas | Matches modern commercial aesthetic for guest seating near elevators or conference entrances | |
| Healthcare and clinic waiting spaces | Easy-to-clean durable upholstery suitable for high-traffic public visitor use | |
| Education and campus common areas | Compact circular layout supports small group collaboration outside classrooms | |
| Recommended configuration | Arrange with 600 mm clearance around the set perimeter for unobstructed pedestrian passage | |
| Surface requirement | Place on level hard flooring or low-pile commercial carpet for stable seating and table placement | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Strength, durability and safety requirements for non-domestic seating, applies to commercial lounge chairs | |
|---|---|---|
| EN 15372:2016 | Strength, durability and safety requirements for non-domestic tables, applies to reception coffee table | |
| EN 1022:2018 | Stability testing standard for domestic and non-domestic seating, applies to fixed lounge armchairs |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Safety and performance standard for lounge and public area seating, applicable to armchairs | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Safety and performance standard for occasional tables, applicable to round coffee table |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminated tabletop and structural components | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to steel chair frames and table pedestal | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to table core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminated tabletop and structural components; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to steel chair frames and table pedestal; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to table core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
