Automatic mm / inch conversion · Core engineering specifications
| Single chair overall dimensions | 584 x 635 x 861 mm | |
|---|---|---|
| Chair seat height | 470 mm | |
| Chair seat width | 520 mm | |
| Chair seat depth | 500 mm | |
| Chair back total height above seat | 391 mm | |
| Chair leg splay base diameter | 660 mm | |
| Side table overall dimensions | 508 mm diameter x 508 mm H | |
| Table tabletop thickness | 64 mm | |
| Table flared pedestal base diameter | 420 mm | |
| Set overall circular arrangement diameter | 2200 mm | |
| Floor clearance under chair seat | 180 mm | |
| Floor clearance under tabletop | 420 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single chair weight capacity | 136 kg | |
|---|---|---|
| Side table top static load capacity | 25 kg | |
| Single chair net weight | 11 kg | |
| Seating capacity | 4 adults | |
| Chair leg floor tip static friction coefficient | 0.6 | |
| Upholstery Martindale abrasion resistance | 30000 cycles | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 55% | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Chair upholstery | Red velvet fabric with 0.8mm pile thickness | |
|---|---|---|
| Chair internal seat/back frame | 15mm thick engineered bent wood shell | |
| Seat and back padding | 80mm thick high-density polyurethane foam with fiber wrap | |
| Chair legs | 12mm diameter chrome-plated cold-rolled steel tubing, splayed configuration | |
| Chair foot pads | 15mm diameter non-slip non-marking rubber floor tips | |
| Side table tabletop | Glossy white fiberglass-reinforced composite with smooth sealed finish | |
| Side table pedestal and base | 2mm thick steel with white powder-coated finish, flared circular base | |
| Table base bottom pad | 2mm thick felt ring to protect hard floor surfaces | |
| Seam construction | 6 stitches per inch straight stitching along upholstery edges | |
| Chrome leg plating thickness | 0.02mm decorative chrome finish over nickel undercoat | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating design | Continuous curved integrated arm/back shell for wrap-around torso support | |
|---|---|---|
| Leg structure | Four splayed metal legs per chair for even weight distribution and tip resistance | |
| Floor protection | Rubber foot pads on all leg ends prevent scratching and reduce movement noise | |
| Table structure | Single central tapered pedestal base creates unobstructed leg room around table | |
| Seating function | Fixed stationary seating with no recline, swivel, or height adjustment mechanisms | |
| Table function | Flat smooth tabletop designed to hold beverages, reading materials, and small decor | |
| Set layout | Circular four-chair arrangement optimized for face-to-face casual conversation | |
| Assembly requirement | Knock-down construction with included hardware for leg and base attachment | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room lounge | Casual conversation seating for small apartments and modern open-plan living spaces | |
|---|---|---|
| Office reception waiting area | Compact 4-guest seating for informal visitor waiting zones with low-traffic use | |
| Hotel lobby breakout area | Small modular seating clusters for guest relaxation and casual meetings | |
| Retail boutique lounge | Seating for customers to rest while shopping in fashion or lifestyle stores | |
| Studio apartment flexible seating | Space-efficient 5-piece set that fits small urban living spaces without bulk | |
| Breakout collaboration zone | Informal small-group discussion seating for creative office environments | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture – Strength, durability and safety for non-domestic seating | |
|---|---|---|
| EN 1022:2018 | Furniture – Seating – Determination of stability | |
| EN 12520:2015 | Furniture – Strength, durability and safety for domestic tables | |
| EN 13722:2004 | Furniture – Test methods for surface resistance to cold liquids for table tops |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | General purpose office chairs – strength and durability reference for light lounge seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Desk products – surface performance reference for pedestal side table tops | |
| ANSI/BIFMA X7.1-2022 | Furniture emissions standard for low-VOC indoor furniture materials |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal chair frame components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to chair legs and table base | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 19001-2016 | Quality management system requirement for furniture manufacturing quality control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal chair frame components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to chair legs and table base; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 4. GB/T 19001-2016: Quality management system requirement for furniture manufacturing quality control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
