Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 720 x 820 x 700 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 18 kg | |
|---|---|---|
| Static seat load capacity | 150 kg | |
| Surface abrasion resistance | 50000 cycles | |
| Product warranty | 3 years | |
| Available color options | 6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core structure | Integral molded high-density rigid polyurethane foam | |
|---|---|---|
| Surface finish | Smooth matte polymer-coated upholstery skin | |
| Floor contact pads | Non-slip 3mm thick TPE rubber pads | |
| Upholstery wear layer | 2mm thick stain-resistant PU coating | |
| Internal core density | 120 kg/m³ rigid foam | |
| Edge finishing | Rounded 20mm radius soft edges | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel | |
| Five-star Base Material Thickness | Metal base wall 3.5 mm; diameter 700 mm | |
| Caster Engineering Specification | 5 PU-tread swivel casters, 60 mm diameter |
Adjustment / rotation / tilt / mobility / storage features
| Assembly requirement | Fully assembled delivery | |
|---|---|---|
| Mobility | Lightweight repositioning by hand | |
| Seating posture support | Contoured 105° fixed recline angle | |
| Maintenance | Wipe-clean surface | |
| Stacking capability | Non-stackable design | |
| Floor protection | Integrated non-marring contact points | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Pairs with small side tables for casual conversational seating layouts | |
|---|---|---|
| Hotel lobby lounge areas | Suitable for modern boutique hotel reception and waiting zones | |
| Office breakout spaces | Provides informal seating for employee relaxation and impromptu meetings | |
| High-end retail waiting areas | Fits luxury retail fitting room and customer waiting zones | |
| Residential balcony spaces | Suitable for covered outdoor use with weather-resistant coated finish | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
