Automatic mm / inch conversion · Core engineering specifications
| Chair overall dimensions | 900 x 900 x 990 mm | |
|---|---|---|
| Chair seat width | 760 mm | |
| Chair seat depth | 620 mm | |
| Chair seat height | 390 mm | |
| Chair backrest height | 600 mm | |
| Chair armrest height | 580 mm | |
| Ottoman overall dimensions | 690 x 580 x 380 mm | |
| Ottoman seat cushion thickness | 120 mm | |
| Frame tubing diameter | 16 mm | |
| Under-seat floor clearance | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 44 kg | |
|---|---|---|
| Chair static weight capacity | 159 kg | |
| Ottoman static weight capacity | 45 kg | |
| Cushion foam density | 40 kg/m³ | |
| Cushion foam rebound rate | 45% | |
| Seam tensile strength at joints | 120 N | |
| Frame static load rating per leg | 100 kg | |
| Limited warranty period | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Chair and ottoman upholstery | 1.2mm thick tan polyurethane faux leather, abrasion-resistant finish | |
|---|---|---|
| Seat and back cushion fill | High-density polyurethane foam wrapped in 20mm soft polyester fiber | |
| Included lumbar pillow fill | 100% recycled polyester fiber fill, removable cover | |
| Structural frame | 1.5mm thick black powder-coated carbon steel tube sled base | |
| Armrest structure | Padded curved steel frame wrapped in matching tan upholstery | |
| Floor protection pads | 5mm thick non-slip polyethylene glides at all frame contact points | |
| Stitching detail | Polyester bonded thread, 8 stitches per inch seam pitch at all panel joints | |
| Backrest internal support | 8mm thick plywood support panel webbed with 50mm elastic webbing | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Backrest posture | Fixed 110-degree reclined angle optimized for relaxed lounging | |
|---|---|---|
| Ottoman positioning | Free-standing, can be positioned for leg rest or use as extra side seating | |
| Cushion design | Loose, reversible seat cushions for even wear over service life | |
| Lumbar support | Removable matching upholstered lumbar pillow for adjustable lower back support | |
| Frame stability | Continuous sled base design eliminates wobble on low-pile carpet and hard floors | |
| Cushion maintenance | Spot-cleanable upholstery with removable cushion covers via hidden zippers | |
| Floor protection | Integrated glides prevent scuffing and scratching on hard flooring surfaces | |
| Assembly requirement | Knock-down assembly with included hardware, leg attachment to pre-upholstered body | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Pair as primary reading or conversation seating next to side tables | |
|---|---|---|
| Office lounge area | Place in reception or breakout spaces for casual visitor seating | |
| Bedroom reading nook | Position near windows as dedicated relaxed seating for private spaces | |
| Hotel guest room seating | Deploy as premium in-room seating paired with side tables for hospitality use | |
| Open-plan studio apartment | Use as dual-purpose seating and footrest without occupying excess floor space | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Domestic furniture seating strength | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture ignitability | EN 1021:2014 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| Upholstery furniture safety | GB 28007 | |
|---|---|---|
| Formaldehyde emission limit | GB 18584 |
This product must meet the following technical requirements: 1. Upholstery furniture safety: GB 28007; 2. Formaldehyde emission limit: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
