Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 1400 × 800 mm | |
|---|---|---|
| Overall set footprint (triangular arrangement) | 1600 x 1400 mm | |
| Side table top diameter | 600 mm | |
| Side table base bottom diameter | 300 mm | |
| Armchair seat height | 400 mm | |
| Armchair seat width | 600 mm | |
| Armchair seat depth | 550 mm | |
| Armchair back height (above seat) | 400 mm | |
| Armchair leg height (floor to seat rail) | 360 mm | |
| Armrest height (above seat) | 180 mm | |
| Floor clearance under side table | 500 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight | 65 kg | |
|---|---|---|
| Single armchair static load capacity | 150 kg | |
| Upholstery fabric abrasion resistance | 30000 Martindale cycles | |
| Seat cushion foam density | 35 kg/m³ | |
| Seat cushion foam thickness | 80 mm | |
| Backrest foam thickness | 50 mm | |
| Side table base stability tip load | 15 kg | |
| Standard residential warranty period | 2 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair upholstery fabric | Mustard yellow woven polyester-linen blend | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam | |
| Backrest core | Medium-density polyurethane foam | |
| Chair internal frame | 15mm thick plywood engineered wood frame | |
| Chair legs | Matte black finished solid rubberwood, tapered profile | |
| Table top | Black matte laminate surface on MDF substrate | |
| Table pedestal base | Black powder-coated conical metal tube | |
| Table accent ring | Brushed copper-toned metal trim ring | |
| Throw pillows | Solid grey woven fabric cover with polyfiber fill | |
| Hardware components | Zinc-plated steel KD assembly hardware | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | 3-person face-to-face triangular layout | |
|---|---|---|
| Back support design | Continuous wrap-around curved barrel back | |
| Armrest design | Integrated curved armrests molded with back frame | |
| Table use purpose | Small footprint occasional surface for drinks and decor | |
| Assembly type | Knock-down (KD) leg and base attachment | |
| Seat construction | Fixed non-reclining padded seat with no tilt mechanisms | |
| Floor protection | Plastic glide feet fitted to all leg and base contact points | |
| Decor accessory inclusion | One matching throw pillow per armchair | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small apartment living room corner | Compact footprint fits limited floor space for casual guest seating | |
|---|---|---|
| Office reception and break-out areas | Relaxed styling for informal waiting areas and employee break spaces | |
| Balcony and sunroom casual seating | Lightweight construction suitable for semi-enclosed indoor lounge spaces | |
| Hotel guest room lounge zones | Curved comfortable design for short-stay guest relaxation and refreshment placement | |
| Cafe and boutique waiting areas | Stylish mustard upholstery creates inviting low-traffic customer seating | |
| Residential entry foyer nook | Small scaled set provides convenient seating for putting on shoes and placing bags | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Residential furniture seating strength, durability and safety requirements | |
|---|---|---|
| EN 15372:2016 | Furniture durability resistance of surfaces to cold liquids and abrasion | |
| EN 1022:2018 | Seating furniture stability test methods for fixed-leg chairs |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and leg components | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control | |
| GB/T 1952.1-2012 | Upholstered furniture seating general requirements, applicable to chair safety and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and leg components; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control; 3. GB/T 1952.1-2012: Upholstered furniture seating general requirements, applicable to chair safety and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
