Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 667 x 672 x 889 mm | |
|---|---|---|
| Seat width | 590 mm | |
| Seat depth | 520 mm | |
| Seat height from floor | 489 mm | |
| Backrest height above seat | 400 mm | |
| Armrest height from floor | 695 mm | |
| Under-seat knee clearance height | 240 mm | |
| Armrest width per side | 60 mm | |
| Plinth base footprint length | 620 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static weight capacity | 150 kg | |
|---|---|---|
| Net weight per unit | 19 kg | |
| Cushion foam density | 40 kg/m³ | |
| Cushion foam rebound rate | 45% | |
| Seam tensile strength | 180 N | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Stackable quantity | 0 units | |
| Limited warranty period | 1 year | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid hardwood with 25mm thick engineered wood corner blocking | |
|---|---|---|
| Upholstery facing | 380gsm textured performance woven fabric, pistachio green color | |
| Seat support system | 80mm wide elastic webbing spaced 80mm apart under seat cushion | |
| Seat cushion padding | 70mm thick high-density polyurethane foam wrapped with 10mm soft Dacron layer | |
| Backrest padding | 40mm thick medium-density polyurethane foam over hardboard back panel | |
| Arm and side panel padding | 20mm thick polyurethane foam over structural frame panels | |
| Base glides | 8mm diameter black non-marking nylon floor glides at plinth base corners | |
| Seam construction | Reinforced straight seams with 8mm stitch pitch on all upholstery joints | |
| Bottom dust cover | Black non-woven polypropylene fabric stapled to plinth base underside | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed upright seating position with 5 degree backward backrest tilt for dining posture | |
|---|---|---|
| Mobility function | Static non-swivel, non-caster design with floor glides for smooth repositioning without scratching | |
| Arm support function | Continuous integrated armrests extending full side panel height for forearm support during seated dining | |
| Floor protection function | Non-marking nylon glides at four base corners to prevent hard floor scratching | |
| Installation requirement | Delivered fully assembled, no on-site assembly required for immediate use | |
| Cleaning function | Stain-resistant performance fabric upholstery allows spot cleaning with mild upholstery detergent | |
| Weight distribution function | Wide enclosed plinth base distributes occupant weight evenly to prevent tipping during use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining room | Seating around standard 750mm high dining tables for everyday family meals | |
|---|---|---|
| Commercial cafe seating | Compact footprint for high-turnover restaurant and coffee shop dining areas | |
| Open office breakout area | Casual seating for informal meetings and lunch breaks in workspaces | |
| Boutique hotel guest room | Seating for vanity desks or small in-room dining nooks in hospitality settings | |
| Residential kitchen island | Perimeter seating for standard kitchen counters at 900mm overhang height | |
| Event venue function space | Formal seating for banquet and conference dining events | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture strength, durability and safety for non-domestic seating, applicable for commercial dining use | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture flammability, cigarette ignition resistance, applicable for fabric and foam components | |
| EN 12520:2015 | Domestic furniture seating safety, strength and durability requirements for residential dining use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal hardwood frame structural integrity | |
|---|---|---|
| GB 28007-2011 | Safety requirements for upholstered furniture, applicable to structural stability and padding safety | |
| GB/T 19833-2019 | Furniture mechanical test methods for seating, applicable for static load and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal hardwood frame structural integrity; 2. GB 28007-2011: Safety requirements for upholstered furniture, applicable to structural stability and padding safety; 3. GB/T 19833-2019: Furniture mechanical test methods for seating, applicable for static load and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
