| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 780 x 820 x 950 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 26 kg | |
|---|---|---|
| Static load capacity | 150 kg | |
| Swivel rotation range | 360 degrees | |
| Recommended maximum user weight | 120 kg | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Foam density (backrest) | 35 kg/m³ | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick matte faux leather | |
|---|---|---|
| Internal frame | 18mm thick plywood frame | |
| Seat cushion padding | High-resilience polyurethane foam | |
| Backrest padding | Shaped polyurethane foam with central gather detail | |
| Swivel stem | Polished chrome-plated steel | |
| Base disc | 2mm thick black powder-coated steel plate | |
| Swivel bearing | Carbon steel rotating bearing | |
| Stitching | Tone-on-tone matching thread with 8mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Swivel mechanism | 360-degree smooth rotation via sealed central bearing | |
|---|---|---|
| Ergonomic back support | Contoured wingback shape with lumbar indentation | |
| Integrated wrapped armrests | Curved upholstered side panels form continuous arm support | |
| Fixed relaxed recline angle | 110 degrees between seat and backrest | |
| Floor protection | Felt pad under steel base disc | |
| No-tip stability | Wide disc base distributes weight evenly across contact area | |
| Maintenance friendly surface | Wipe-clean faux leather finish | |
| Swivel stem diameter | 50 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office lounge areas | Suitable for waiting zones and informal collaboration spaces with modern aesthetic | |
|---|---|---|
| Hotel lobbies and guest areas | Provides comfortable guest seating that complements contemporary interior design | |
| Residential living rooms | Works as accent seating in open-plan living spaces or home lounge areas | |
| Reception areas | Creates welcoming seating for visitors in corporate or retail reception zones | |
| Cafe and co-working spaces | Supports casual meetings and relaxed work sessions in flexible work environments | |
| Pairing configuration | Designed to be paired with small pedestal side tables for drink and accessory placement | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
