Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 840 x 680 x 800 mm | |
|---|---|---|
| Seat width | 640 mm | |
| Seat depth | 560 mm | |
| Seat height | 495 mm | |
| Backrest height | 356 mm | |
| Armrest height | 650 mm | |
| Cushion thickness | 190 mm | |
| Leg width | 120 mm | |
| Gold accent band width | 20 mm | |
| Under-seat frame clearance | 180 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 159 kg | |
|---|---|---|
| Net weight | 23 kg | |
| Foam density | 40 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Seam pitch | 8 mm | |
| Warranty period | 1 year | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Terracotta textured woven fabric | |
|---|---|---|
| Seat cushion fill | High-resilience polyurethane foam | |
| Back and arm fill | Medium-density polyurethane foam over webbing support | |
| Internal frame | 18mm thick solid kiln-dried hardwood | |
| Structural bracing | 1.5mm thick polished gold-finish steel U-frame | |
| Accent trim | Polished gold-plated steel joint bands | |
| Edge finish | Dark contrast piping along all upholstery panel seams | |
| Floor glides | Non-slip plastic foot pads | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Single-seat enclosed barrel design with wrap-around integrated armrests | |
|---|---|---|
| Structural support | Three upholstered vertical legs connected via under-seat gold metal U-frame | |
| Floor protection | Non-marking glides prevent scuffing on hard flooring surfaces | |
| Assembly requirement | Minimal assembly of seat cushion to pre-attached frame structure | |
| Position type | Fixed upright seating angle for lounge or casual guest use | |
| Color option baseline | Available in terracotta upholstery with polished gold metal trim | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Suitable as standalone accent seating next to sofas or coffee tables | |
|---|---|---|
| Bedroom vanity or reading nook | Provides upright supportive seating for personal dressing or casual reading | |
| Office reception and lounge areas | Functions as guest seating in contemporary office welcome zones | |
| Boutique waiting areas | Serves as decorative, comfortable seating in retail or salon waiting spaces | |
| Hotel guest room seating | Works as corner accent seating in boutique hotel room layouts | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable for strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Applicable for upholstered furniture ignitability resistance to cigarette sources |
US and Canada office-furniture standards
| ANSI/BIFMA X5.41-2020 | Applicable for lounge seating structural performance validation for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.4-2020 | Applicable for public and lounge seating stability and load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture frames | |
|---|---|---|
| GB 20400-2006 | Applicable for leather/fabric furniture harmful substance limit testing | |
| GB/T 3920-2008 | Applicable for upholstery fabric color fastness to rubbing testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture frames; 2. GB 20400-2006: Applicable for leather/fabric furniture harmful substance limit testing; 3. GB/T 3920-2008: Applicable for upholstery fabric color fastness to rubbing testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
