Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 980 × 860 × 810 mm | |
|---|---|---|
| Seat height from floor | 480 mm | |
| Seat width | 570 mm | |
| Seat depth | 560 mm | |
| Backrest height from seat | 440 mm | |
| Armrest height from seat | 130 mm | |
| Seat cushion thickness | 200 mm | |
| Armrest cushion thickness | 180 mm | |
| Plinth base height | 40 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 36 kg | |
|---|---|---|
| Recommended static load capacity | 150 kg | |
| Seat foam density | 40 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery fabric abrasion resistance | 30000 Martindale cycles | |
| Seam stitching pitch | 8 mm | |
| Available color options | 9 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery fabric | 100% polyester plush fuzzy fleece, 1.2 mm thickness | |
|---|---|---|
| Seat core filling | High-density polyurethane foam with wrapped polyester fiber | |
| Backrest filling | Blended high-resilience foam and polyester fiber | |
| Integrated armrest filling | Dense polyurethane foam with soft fiber wrap | |
| Internal support frame | 25 mm thick engineered hardwood plywood | |
| Plinth base | Dark brown finished engineered wood with anti-slip felt bottom | |
| Seam construction | Reinforced polyester stitching with matched blush pink thread | |
| Under-base padding | 3 mm thick non-slip felt pad | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Single-person stationary lounge seat with full wraparound back support | |
|---|---|---|
| Integrated armrest support | Padded bulbous armrests extending continuously from seat to backrest | |
| Base design | Low-profile enclosed plinth base with no exposed legs | |
| Upholstery care | Surface cleanable with soft damp cloth and mild neutral soap | |
| Assembly requirement | Minimal base attachment assembly required | |
| Mobility design | Stationary placement without swivel, recline, or wheeled movement | |
| Edge design | Fully rounded soft edges across all padded surfaces | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room placement | Position as standalone accent seating or paired with sofas for casual relaxation spaces | |
|---|---|---|
| Bedroom casual seating | Place near vanities or windows to create cozy dedicated reading corners | |
| Lounge and waiting area use | Install in boutique hotel lobbies or creative studio break areas for soft welcoming seating | |
| Target user group | Suitable for adult users seeking low-profile, soft, design-focused casual leisure seating | |
| Recommended pairing | Coordinate with round low-profile coffee tables and soft area rugs for cohesive modern organic interiors | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture flammability test for cigarette ignition resistance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable for wooden frame domestic furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit applicable for wood-based panel frame components | |
| GB/T 19867.1-2015 | Strength and durability test method applicable for domestic seating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable for wooden frame domestic furniture; 2. GB 18580-2017: Formaldehyde emission limit applicable for wood-based panel frame components; 3. GB/T 19867.1-2015: Strength and durability test method applicable for domestic seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
