| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 760 x 870 x 850 mm | |
|---|---|---|
| Seat height | 510 mm | |
| Seat width | 620 mm | |
| Seat depth | 560 mm | |
| Seat cushion thickness | 140 mm | |
| Backrest height | 340 mm | |
| Back cutout dimensions | 380 x 120 mm | |
| Leg cross-section dimension | 120 x 120 mm | |
| Under-seat clearance | 160 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 159 kg | |
|---|---|---|
| Net product weight | 25 kg | |
| Seat foam density | 40 kg/m³ | |
| Foam rebound rate | 55% | |
| Upholstery fabric abrasion resistance | 30000 Martindale cycles | |
| Frame joint static load rating | 200 kg | |
| Anti-slip pad floor friction coefficient | 0.6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | Dark green textured woven polyester, 0.8mm thick, anti-pilling treated | |
|---|---|---|
| Internal frame | 18mm thick reinforced engineered plywood frame with corner blocking | |
| Seat padding | High-density polyurethane foam core wrapped with 20g soft polyester batting | |
| Backrest padding | 30mm thick high-density foam over frame to maintain rigid sculpted form | |
| Leg construction | Fully upholstered integrated block legs matching frame structure, no exposed hardware | |
| Foot pads | 8mm thick black non-marking rubber anti-slip pads bonded to each leg base | |
| Seam detailing | Matching dark green piped edging along all upholstery seams, 8mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel | |
| Five-star Base Material Thickness | Metal base wall 3.5 mm; diameter 700 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed armless single-person seating for residential lounge or dining use | |
|---|---|---|
| Floor protection | Integrated rubber foot pads prevent scuffing and sliding on hard wood or tile floors | |
| Structural stability | Four wide block legs create a low center of gravity to prevent tipping under normal use | |
| Back support | Curved-top upright backrest with open cutout provides lumbar support while reducing visual bulk | |
| Placement flexibility | Compact armless footprint fits in dining nooks, living room corners, entryways, or bedroom vanities | |
| Cleaning access | Smooth seamed upholstery allows spot cleaning without removable cushions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Gross shipping weight | 28 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining spaces | Fits standard 750mm high dining tables as a stylish armless side chair | |
|---|---|---|
| Living room accent seating | Serves as a decorative side chair next to sofas, coffee tables, or reading nooks | |
| Entryway and foyer use | Compact footprint fits narrow entryways as functional seating for putting on shoes | |
| Bedroom vanity seating | Armless design slides easily under standard height vanity tables for grooming use | |
| Commercial lounge spaces | Suitable for boutique waiting areas, cafe seating, or hotel guest room accents | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Seating strength recommendation | EN 12520:2015 | |
|---|---|---|
| Fabric upholstery flammability recommendation | EN 1021:2014 |
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18584 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Formaldehyde emission recommendation: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
