Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 2400 × 780 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single chair static load capacity | 150 kg | |
|---|---|---|
| Total set net weight | 72 kg | |
| Seat foam density | 35 kg/m³ | |
| Seat foam thickness | 80 mm | |
| Recommended maximum seating capacity | 4 people | |
| Frame finish corrosion resistance | 48 hours | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair seat and inner back upholstery | Woven matte polyester fabric, soft-touch | |
|---|---|---|
| Chair outer back upholstery | Contrast matte PU leather, two-tone color design | |
| Chair internal frame | 1.2 mm thick welded steel tube, powder-coated black | |
| Chair leg feet | Non-marking plastic glide caps | |
| Cushion filling | High-resilience polyurethane foam | |
| Table top | 12 mm thick high-gloss sintered stone / engineered marble | |
| Table support frame | 2 mm thick matte black powder-coated steel | |
| Upholstery stitching | Contrast fine stitching, 6 stitches per 30mm | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Enclosed armrest design | Integrated curved armrests formed by upholstered side panels | |
|---|---|---|
| Fixed non-reclining backrest | Curved ergonomic back set at 105 degree relaxed angle | |
| Stable tripod table base | Three outstretched steel legs with connecting cross brace | |
| Floor protection | Plastic glides on all furniture legs | |
| Modular set arrangement | Chairs can be repositioned freely around the central table | |
| Stain-resistant table surface | Non-porous high-gloss tabletop | |
| Color-variant upholstery | Chairs available in pink/beige/brown two-tone finishes | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total packing carton count | 5 cartons | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception lounge areas | Provides casual seating for short visitor waiting and informal conversation | |
|---|---|---|
| Hotel lobby break-out spaces | Matches modern hospitality interior designs with two-tone color options | |
| Co-working space common areas | Accommodates informal team discussions and short work breaks | |
| Residential living room supplementary seating | Adds stylish conversation seating for home lounge or balcony areas | |
| Cafe and tea house seating | Creates intimate 4-person seating clusters for light dining and drinks | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office lounge seating stability recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface fire resistance recommendation | EN 1021:2014 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Lounge seating durability recommendation | ANSI/BIFMA X2020 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture structural safety recommendation | GB 28007 | |
|---|---|---|
| Furniture harmful substance limit recommendation | GB 18584 |
This product must meet the following technical requirements: 1. Upholstered furniture structural safety recommendation: GB 28007; 2. Furniture harmful substance limit recommendation: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
