Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 790 x 800 x 865 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat depth | 500 mm | |
| Seat width | 580 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest height from seat | 405 mm | |
| Armrest height from floor | 670 mm | |
| Leg height | 380 mm | |
| Floor clearance under seat | 150 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight | 12 kg | |
|---|---|---|
| Recommended static load capacity | 120 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Leg static load rating per leg | 50 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer back and armrest upholstery | Deep terracotta polyester velvet, 1.2 mm thick | |
|---|---|---|
| Central backrest panel upholstery | Bright orange polyester velvet, 1.2 mm thick | |
| Seat cushion top upholstery | Light tan polyester velvet, 1.2 mm thick | |
| Inner structural frame | 18 mm FSC-certified plywood composite | |
| Cushion core | High-density polyurethane foam wrapped in 20 mm Dacron batting | |
| Support legs | 1.5 mm thick powder-coated matte black tapered steel | |
| Seat suspension layer | Polypropylene webbing straps 50 mm wide | |
| Seam construction | Twin-needle stitching at 6 mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Single occupant fixed lounge seating, no recline or swivel mechanism | |
|---|---|---|
| Leg assembly | Knock-down leg attachment with M8 threaded inserts and included hardware | |
| Armrest integration | Continuous wraparound armrests merged with backrest for enclosed side support | |
| Floor protection | Nylon glide pads fitted to each leg base to prevent hard floor scratches | |
| Back support angle | 105 degrees from seat plane for relaxed lounge posture | |
| Stability design | Splayed outward angled legs for 720 mm effective support base width | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room | Place as standalone accent seating next to sofas or side tables for relaxed guest use | |
|---|---|---|
| Bedroom reading corner | Pair with a small side table for dedicated quiet reading or dressing area seating | |
| Office reception waiting areas | Deploy in multiples for modern, warm-toned visitor waiting zone seating | |
| Cafe and lounge breakout spaces | Arrange around low coffee tables for casual customer seating | |
| Hotel guest room corners | Position as supplementary guest seating in boutique or mid-tier hotel rooms | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength, durability and safety performance benchmark | |
|---|---|---|
| EN 1022:2018 | Seating stability test standard applicable for four-leg domestic lounge chairs |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating performance standard for light commercial space suitability | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office chair strength reference for structural load validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to plywood frame evaluation | |
|---|---|---|
| GB 20400-2006 | Leather and fur harmful substance limit, applies to velvet textile formaldehyde limits as reference | |
| GB/T 19001-2016 | Quality management system guidance for consistent furniture production processes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to plywood frame evaluation; 2. GB 20400-2006: Leather and fur harmful substance limit, applies to velvet textile formaldehyde limits as reference; 3. GB/T 19001-2016: Quality management system guidance for consistent furniture production processes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
