Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 705 x 650 x 940 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat width | 660 mm | |
| Seat depth | 584 mm | |
| Backrest height above seat | 490 mm | |
| Armrest height above seat | 210 mm | |
| Leg taper angle | 12 degrees outward | |
| Leg diameter at floor contact | 18 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 18 kg | |
|---|---|---|
| Recommended static load capacity | 159 kg | |
| Seat cushion foam density | 38 kg/m³ | |
| Cushion foam rebound rate | 45% | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Warranty period | 2 years | |
| Available color variants | 6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and lower arm upholstery | Textured heathered woven polyester fabric | |
|---|---|---|
| Upper backrest upholstery | Smooth matte woven fabric in darker taupe | |
| Seat cushion fill | 38kg/m³ high-resilience polyurethane foam | |
| Backrest fill | 28kg/m³ soft-support polyurethane foam | |
| Inner support frame | 12mm thick plywood frame with metal hardware | |
| Support legs | 1.2mm thick steel with brushed brass finish | |
| Seat base support | Sinuous spring suspension under cushion | |
| Upholstery stitching | 8 stitches per inch matching tone thread | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Single-person fixed upholstered seating with wrap-around back support | |
|---|---|---|
| Armrest function | Integrated continuous arm support wrapping from back to front seat edge | |
| Mobility feature | Non-stackable, fixed-position seating without casters | |
| Assembly requirement | Partial assembly required, attaching legs to pre-upholstered seat body | |
| Surface protection | Non-marking plastic glide fitted to each leg base | |
| Use adaptability | Dual-height compatible for dining tables and accent side table pairing | |
| Back support | Arched curved back with lumbar-aligned padding | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining spaces | Pairs with standard 750mm height dining tables for mixed-material dining sets | |
|---|---|---|
| Home office guest seating | Fits alongside desks as visitor seating without casters | |
| Bedroom vanity seating | Provides upright support at 750mm height vanity tables | |
| Living room accent seating | Functions as standalone side chair next to coffee tables or sofas | |
| Lounge breakout areas | Suitable for casual office breakout spaces waiting areas | |
| Foyer entryway seating | Provides temporary perching in entry zones | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
